When the CSC validates the control a timeout must be specified: it defines the
time during which the MorphoAccess
signal from the CSC through LED IN signals.
LED IN acknowledgement timeout in 10 ms
app/led IN/controller ack timeout
If the controller has only one LED signal dedicated to "access authorized", this
signal must be connected to LED1 input. In this case "access forbidden" signal
will be based on a timeout. "controller ack timeout" value must be defined as
short as possible in a range corresponding to controller reply delay.
A controller with distinct outputs (one for "access forbidden", one for "access
authorized") has to be connected to LED1 and LED2 I/O board
