This mode is also useful to use the card serial number as user's identifier.
Binary identifier, non-structured data
app/contactless/data format
Binary data are defined by their position from the first read block.
User ID length is limited to 8 bytes (app/contactless/data length 8.0).
User ID offset is limited to 15 bytes (app/contactless/data offset 15.0).
Data localization
app/contactless/B
app/contactless/data length
app/contactless/data offset
The interpretation (little or big endian) of the data can be defined.
Data interpretation
app/contactless/data type
A user's record with the same User ID value, and user's fingerprint templates
must exist in the local database of the MorphoAccess
Authentication process is exactly the same as the one presented above.
Example - 4 bytes identifier.
The terminal is configured to read 4 bytes.
Read bytes are F4 E1 65 34.
Corresponding user identifier in the local database is "4108412212" (ASCII).
Example - reading a MIFARE
app/contactless/data format= 1
app/contactless/data type= 0.1
app/contactless/data length = 4.0
app/contactless/data offset= 0.0
app/contactless/B= 1
1.0 - M
ERSION AY
- R D
EPRODUCTION AND ISCLOSURE
Access control by authentication
[number of bytes].[additional bits]
[number of bytes].[additional bits]
0.1 (binary data, MSB first)
0.0 (binary data, LSB first RFU)
®
card Serial Number (big endian format).
2010
P
ROHIBITED
1 (binary data)
[1-215]: read block
®
.
