1. M orp h oRa pI D™ S p ec i f ic a tion s
•
Size: 3.7"
Display
•
VGA Display: 640 x 480 high resolution LCD Touch Panel
65536 Full-Colors
•
•
500 DPI in X and Y axis
Fingerprint Sensor
•
8-bit gray scale
Acquisition area 21 x 21 mm (0,8 x 0,8 ")
•
•
HSDPA/EDGE/GPRS
Wireless modem
•
850 / 900 / 1800 / 1900 / 2100 MHz frequencies
•
802.11b/g radio module
WiFi interface
•
Bluetooth v2.0, Class II module
Bluetooth interface
ISO 14443A/B/Mifare 13.56MHz High Frequency reader
•
RFID reader
•
ISO 7816 smartcard reader
Smartcard reader
•
2D imager to read linear (1D) and 2D barcodes (including PDF417)
2D imager
Input/Output
USB 2.0
Power
PSA 15R-050P Model
- Input: AC 100-240 V~ 50-60 Hz 0.5 A
- Output: DC 5.0 V
•
Operating +0°C to 45°C
Temperature Range
•
Storage -20°C to 70°C
0000025754-07 - AUGUST 2009
S
S
D
- R
AGEM
ÉCURITÉ
OCUMENT
EPRODUCTION AND
R
O R P H O
A P
U
S E R
Technical Specifications
3.0 A
D
P
.
ISCLOSURE
ROHIBITED
MorphoRapID™ Specifications
ID Q
U I C K
'
G
S
U I D E
1
Advertisement
Related Manuals for Sagem Securite Morpho RapID Series
Summary of Contents for Sagem Securite Morpho RapID Series
- Page 1 ™ R ID Q ’ MorphoRapID™ Specifications ORPHO UICK UIDE ID Q O R P H O U I C K ’ S E R U I D E 1. M orp h oRa pI D™ S p ec i f ic a tion s Technical Specifications •...
- Page 2 ™ R ID U ’ MorphoRapID™ Specifications ORPHO UIDE Operating 15% < RH < 95% non-condensing • Humidity • Storage < 95% Weight 800 g Dimensions 89 x 126 x 185 mm A removable power cord connects the MorphoRapID™ to the mains supply - Its socket- NOTE outlet shall be near the MorphoRapID™...
- Page 3 ™ R ID QUICK U ’ International Standards ORPHO UIDE 2. In t e rn at ion a l S t an d a rd s The MorphoRapID™ terminal and accessories comply with both European and U.S. standards as follows: Region Standards Europe...
- Page 4 ™ R ID U ’ MorphoRapID™ Specifications ORPHO UIDE Changes or modifications not expressly approved by the party responsible for the WARNING compliance could void the user’s authority to operate the equipment. Canada This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regu- lations.
- Page 5 ™ R ID QUICK U ’ Cleaning ORPHO UIDE 3. Cl e an in g Clean the MorphoRapID™ body, screen and biometric sensor with a dry, non-abrasive, lint-free cloth and only with a cleaning product recommended by Sagem Sécurité. During periods of intense activity, the sensor should be cleaned as soon as smears are visible on-screen. Avoid using any alcohol or by-products that could damage the WARNING MorphoRapID™...
- Page 6 ™ R ID QUICK U ’ Battery ORPHO UIDE 4. B att e r y Precautions Battery Handling MorphoRapID™ The battery handling precautions for batteries are: • The battery used in this device may present a fire or chemical burn hazard if WARNING mistreated.
- Page 7 ™ R ID QUICK U ’ Battery ORPHO UIDE Battery Transportation It is recommended to remove batteries from the terminal when the product is transported on long distance. Battery Charge MorphoRapID™ It is mandatory to only use the battery charger delivered by Sagem Sécurité for the MorphoRapID™...
-
Page 8: Battery Replacement
™ R ID QUICK U ’ Battery ORPHO UIDE Battery Replacement Here are the instructions to replace the battery: Screen Action 1 At the back of the device, unlatch the battery cover latches. 2 Open the battery compartment by pulling and sliding its cover. - Page 9 ™ R ID QUICK U ’ Battery ORPHO UIDE Screen Action 4 Replace the discharged battery by the charged one: insert the new battery. 5 Close the battery compartment. 6 Latch the battery compartment. 0000025754-07 - AUGUST 2009 AGEM ÉCURITÉ OCUMENT EPRODUCTION AND ISCLOSURE...
- Page 10 ™ R ID QUICK U ’ Battery ORPHO UIDE Battery Level Management Battery Icon The battery level is shown as a battery icon at the bottom of M The battery levels are detailed in the following table: MorphoRapID™ Use Icon Battery Full optimal...
- Page 11 ™ R ID QUICK U ’ Battery ORPHO UIDE Battery Level Battery Level Percentage Check To check the battery level, proceed as follows: Screen Action Start the MorphoRapID™ terminal. Press, SETTINGS then POWER. Check the battery level. → Proceed to charging the battery if needed. to go back to the M Click 0000025754-07 - AUGUST 2009...
-
Page 12: Power Management
™ R ID QUICK U ’ Recommendations ORPHO UIDE Power Management Description provides a means of: OWER ANAGEMENT •knowing battery power level, •setting power saving, • setting terminal back light. The terminal backlight setting can also be accessed by clicking on the NOTE Sagem Sécurité... -
Page 13: Areas Containing Combustibles
™ R ID U ’ Recommendations ORPHO UIDE Areas Containing Combustibles It is strongly recommended not to install the Sagem Sécurité MorphoRapID™ in the vicinity of gas stations, petroleum processing facilities or any other facility containing flammable or combustible gas or materials.
