Proxy mode
" "
DOCUMENT SSE-0000077399-01 - V
S S D
AGEM ÉCURITÉ OCUMENT
UDP/TCP User Id Emission
The ID of the recognized user can be sent through the IP link (Ethernet or
TM
Wi-Fi ) using UDP or TCP protocol (unsecured TCP or SSL).
The administrator may select the port adress.
See SSL Solution for MorphoAccess
RS485 User ID emission
The ID of the recognized user can be sent through RS485.
Please refer to MorphoAccess
information about the format of the User ID message sent through an IP link
and through a RS485 port.
Wi-Fi TM
Instead of Ethernet connection, the terminal can be connected using a wireless
b/g connection. Please refer to paragraphs "Network Wi-Fi™ configuration"
and "Wi-Fi™ configuration".
The message format and the protocols supported are the same: UDP, TCP or
SSL.
It is not possible for a terminal to be connected through Ethernet and through
Wi-Fi™ at the same time.
Access request result : Local Diary (log)
When enabled, the terminal creates a record for each access request in a local
file. Each record includes: the date/hour of the access request, the user
identifier (if available) and the result of the access rights local check.
The content of this file can be downloaded by the Host System.
The capacity of the file is 8 000 records: when the file is full, the recording of
access request result automatically stops.
The record file can be erased using relevant command, by the Host System.
Proxy mode is not, strictly speaking, a recognition mode. In this mode, the
®
MorphoAccess works as a slave, waiting for external orders such as:
• user identification,
• user verification,
• relay activation,
• read data on a contactless smart card,
• ...
1.0 - M
ERSION AY
- R D
EPRODUCTION AND ISCLOSURE
®
documentation for details about SSL.
®
Remote Messages Specification for more
