Access control by authentication

Authentication based on contactless card mode

50
Example - reading 32-bits identifier in a complete Wiegand frame.
The card contains at sector 15 a complete 37 bits Wiegand frame (including
parity bits, site code).
On this example a 32 bits identifier begins at bit four, parity bits are noted "P".
The corresponding configuration will read only the 32 bits ID on the card.
app/contactless/data format = 1
app/contactless/data type = 0.1
app/contactless/data length = 4.0
app/contactless/data offset = 0.4
app/contactless/B = 46
It is possible to configure the MorphoAccess
bits.
Authentication with contactless card mode
app/bio ctrl/authent card mode
In this mode the user's card decides of the type of control to perform.
The CARD MODE tag is required on the user's card. This tag can take several
values.
• PKS [0x02]: fingerprint check required. The user identifier, template 1 and
template 2 are required on the card. The authentication process is identical
to "authentication with user's fingerprint templates on contactless card".
• ID_ONLY [0x01]: fingerprint check disabled. Only the user identifier is
required on the user's card. There is no biometric control, the control is
immediately positive. This feature is useful for visitor requiring an access
without enrolment. Even if user's fingerprints are stored on the user's card,
the terminal doesn't process it..
DOCUMENT SSE-0000077399-01 - V
S S D
AGEM ÉCURITÉ
M A
ORPHO CCESS
Binary identifier read in MSB
ID begins bit 4 of sector 15
®
Wiegand output to add parity
- R
OCUMENT EPRODUCTION AND
® J S – User Guide
ERIES
Binary identifier
4 bytes length
Read at sector 15
1 (Enabled)
