Summary of Contents for Dürkopp Adler 667 PREMIUM

  • Page 1 667 PREMIUM Operating Instructions...
  • Page 2 IMPORTANT READ CAREFULLY BEFORE USE KEEP FOR FUTURE REFERENCE All rights reserved. Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents, including extracts, is prohibited without the prior written approval of Dürkopp Adler AG. Copyright © Dürkopp Adler AG 2018...

  • Page 3: Table Of Contents

    Selecting the quick access function (softkey menu)......54 5.4.2 Setting the Speed parameter (Max Speed)........57 5.4.3 Setting the Thread cutter parameter (Thread Trim) ......57 5.4.4 Setting the Thread clamp parameter (Thread Clamp)...... 58 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 4 Checking the scope of delivery ............109 Removing the transport locks ............109 Assembling the stand ................ 110 Assembling the pedal and setpoint device ........111 Tabletop .................... 112 7.5.1 Completing the tabletop ..............112 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 5 Disposal ................... 133 Troubleshooting ................135 10.1 Customer Service ................135 10.2 Messages of the software ..............135 10.3 Errors in sewing process ..............136 Technical data ................. 139 Appendix ..................141 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 6 Table of Contents Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 7: About These Instructions

    Specifically, the chapter Setup ( p. 109) is important for specialists. Service Instructions are supplied separately. With regard to minimum qualification and other requirements to be met by personnel, please also follow the chapter Safety ( p. 9). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 8: Representation Conventions - Symbols And Characters

    Lists are marked by bullet points.  Result of performing an operation Change to the machine or on the display/control panel. Important Special attention must be paid to this point when performing a step. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 9: Other Documents

    Each manufacturer has performed a hazard assessment for these purchased parts and confirmed their design compliance with applicable European and national regulations. The proper use of the built-in components is described in the corresponding manu- facturer's instructions. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 10: Liability

    This will ensure any claims against the transport company. Report all other complaints to Dürkopp Adler immediately after receiving the product. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 11: Safety

    The power plug may only be assembled to the power cable by qualified specialists. Obligations Follow the country-specific safety and accident prevention regu- of the operator lations and the legal regulations concerning industrial safety and the protection of the environment. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 12: Signal Words And Symbols Used In Warnings

    Signal words Signal words and the hazard they describe: Signal word Meaning DANGER (with hazard symbol) If ignored, fatal or serious injury will result WARNING (with hazard symbol) If ignored, fatal or serious injury can result Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 13 NOTICE (without hazard symbol) If ignored, property damage can result Symbols The following symbols indicate the type of danger to personnel: Symbol Type of danger General Electric shock Puncture Crushing Environmental damage Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 14 Consequences of non-compliance. Measures for avoiding the danger.  This is what a warning looks like for a hazard that could result in moderate or minor injury if the warning is ignored. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 15 Type and source of danger! Consequences of non-compliance. Measures for avoiding the danger.  This is what a warning looks like for a hazard that could result in environmental damage if ignored. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 16 Safety Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 17: Machine Description

    ③ (1) - Programmable (4) - Oil level indicator thread tension (5) - Winder (2) - Push buttons (6) - Electronic handwheel (3) - Stitch adjustment lever (7) - Control panel OP3000 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 18: Proper Use

    DIN EN 60204-31. Only authorized persons may work on the machine. Dürkopp Adler cannot be held liable for damages resulting from improper use. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 19: Declaration Of Conformity

    Machine description Declaration of Conformity The machine complies with European regulations ensuring health, safety, and environmental protection as specified in the declara- tion of conformity or in the declaration of incorporation. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 20 Machine description Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 21: Operation

    Complete the following steps in preparation of sewing before starting to work: • Inserting/changing the needle • Threading the needle thread • Inserting and winding on the hook thread • Setting the thread tensions Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 22: Switching On And Off The Machine

     The indicator LED (1) and the POWER LED (3) illuminate. Switching off the machine To switch off the machine: Press the switch (2) to the O position.  The indicator LED (1) and the POWER LED (3) go out. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 23: Switching On And Off The Sewing Lamp

    Press button (2) if the sewing lamp is not yet illuminated. Switching off the dimmable sewing lamp To switch off the dimmable sewing lamp: Press switch (1) or (3) to the O position.  The dimmable sewing lamp goes out. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 24: Inserting/Changing The Needle

    Check the distance to the hook tip after inserting a needle with a different thickness. Fig. 4: Inserting/changing the needle ① ② ② ③ (1) - Needle bar (3) - Groove (2) - Screw Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 25 An incorrect hook distance can cause the following disturbances: • Changing to a thinner needle: • Missing stitches • Thread damage • Changing to a thicker needle: • Damage to the hook tip • Damage to the needle Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 26: Threading The Needle Thread

    ② (1) - Hose guide (2) - Thread guide To thread the needle thread: Fit the thread reel on the reel stand. The unwinding bracket must stand directly above the thread reel. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 27 Feed the thread clockwise around tensioner 2 (7). Feed the thread under the thread guide (6) to the thread tension spring (5). Lift the tightening lever (3) with the thread. Pull the thread under the spring tip (4). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 28 12. Insert the thread from the right to the left through the thread lever (16). 13. Insert the thread through the upper thread guide (12). 14. Insert the thread through a hole in the lower thread guide (13). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 29 18. Feed the thread through the thread guide (14) on the needle bar. 19. Insert the thread through the needle eye in such a way that the loose thread end faces the hook. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 30: Winding The Hook Thread

    Risk of injury from needle tip and moving parts! Puncture, cutting and crushing possible. Turn off the machine before threading the thread. Fig. 9: Winding the hook thread (1) ① ② (1) - Thread guide (2) - Hose guide Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 31 Insert the thread in a wavelike manner through the 2 holes of the thread guide (3): from bottom to top through the left hole and from top to bottom through the right hole. Guide the thread to the bobbin (6). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 32 13. Pull off the full bobbin. 14. Tear off the thread behind the cutter (9). 15. Insert the full bobbin into the hook ( p. 31). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 33: Changing The Bobbin

    Removing an empty bobbin Move the needle to the top dead center. Lift the bobbin case retainer (6). Remove the bobbin case upper section (2) with the empty bobbin. Remove the empty bobbin. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 34: Thread Tension

    ② ③ DA150018_V52_XX (1) - Identical needle thread and hook thread tension (2) - Hook thread tension higher than needle thread tension (3) - Needle thread tension higher than hook thread tension Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 35: Setting The Needle Thread Tension

    Switch off the machine before setting the hook thread tension. Fig. 14: Setting the hook thread tension (1) Proper setting The hook thread tension must be set so that the resulting seam pattern is uniform. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 36 Set the tension spring (2) using the adjusting screw (3). • To increase the tension: Turn the adjusting screw (3) clockwise • To reduce the tension: Turn the adjusting screw (3) counterclockwise Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 37: Setting The Needle Thread Regulator

    • To increase the tension: Slide the needle thread regulator (2) to the right • To reduce the tension: Slide the needle thread regulator (2) to the left Tighten the screw (1). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 38: Lifting The Sewing Feet

    The sewing feet remain up as long as the pedal is pressed halfway back. Press the pedal (1) fully back.  The thread cutter is activated, and the sewing feet are raised. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 39: Sewing Backwards With The Stitch Adjustment Lever (Optional)

    To sew backwards with the stitch adjustment lever: Slowly push the stitch adjustment lever (1) down.  The stitch length becomes smaller. In the lower end position, the machine sews backwards with the set stitch length. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 40: Setting Quick Stroke Adjustment

     The increased sewing foot stroke is retained as long as the knee button is pushed to the right. • To switch off the increased sewing foot stroke: Release the knee button (1). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 41: Quick Functions On The Push Buttons

    Press the desired button again.  Function is deactivated. The button turns off. Information The function buttons can be expanded by an additional button. The button can be assigned 2 additional functions. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 42 Fully customizable The button is fully customizable. The machine comes configured so that the machine will switch to the next seam section when the button is pressed. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 43: Assigning A Function To The Favorite Button

    Turn all screws to their initial position (3) so that the slots of the screws are horizontal. Turn the screw (2) under the desired button 90° so that the slot is vertical (4). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 44: Sewing

    Do not press the pedal when you fingers are in the area of the needle tip. Fig. 22: Sewing ① ② ③ ④ (1) - Position +1 (3) - Position -1 (2) - Position 0 (4) - Position -2 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 45 • Switch on the increased sewing foot stroke with the thicker parts of knee button ( p. 38). the material Changing the • 2 stitch length must be activated using the button stitch length on the push buttons ( p. 39). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 46 • Press the pedal fully back (position -2) and keep it seam and there. End bartack is sewn, and thread is cut (if set). remove the Machine stops. sewing Needle is up. Sewing feet up. material • Remove the sewing material. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 47: Programming

    • Exit the menu (changes remain saved) to return to the starting level • Confirm the settings • Activate the input Function is different for each menu. Function is different for each menu. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 48 Display on the control panel The display shows the menu items that can be selected. The activated menu point is shown inverted. Fig. 24: The active entry is shown inverted (example) 4 +000 +00 -013 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 49: Switching On The Machine

    Switching on the machine Fig. 25: Switching on the machine ① (1) - Main switch To switch on the machine: Switch on the main switch (1).  The display briefly shows the software versions: Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 50 The display shows the program last used, or Manual mode. Fig. 27: Display of the program last used (Automatic mode) 4 +000 +00 -013 Fig. 28: Display in Manual mode 5 3.0 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 51: Software Operating Modes

    Edit mode can be used to adjust, delete and copy seam programs. The individual modes and their uses are explained in detail later on. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 52: Using Manual Mode

    Stitch length Value range: 00.0 - 12.0 [mm] (depending on the sewing equipment and the subclass) • Use ◄/► to select the Stitch length parameter • Use ▲/▼ to change the stitch length Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 53 • Use ▲/▼ to change the sewing foot pressure Sewing foot stroke Value range: 00.0 – 09.0 [mm] (0.5 mm increments) • Use ◄/► to select the Stroke height parameter • Use ▲/▼ to change the stroke height Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 54 • Cancel the function • Exit the menu (changes remain saved) to return to the starting level • Confirm the settings • Activate the input Create a program,  p. 84. No function assigned Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 55 For an explanation on how to activate the fast menu keys, refer to the  Service Instructions. Symbol Meaning Start bartack (off/single/double) End bartack (off/single/double) Thread cutter (active/inactive) Needle position (bottom/top) Sewing foot position (bottom/top) Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 56: Selecting The Quick Access Function (Softkey Menu)

    There are various options available to assign to the softkey button depending on whether this is before the seam or in the seam. To exit the menu, press the ESC button or the softkey menu button. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 57 (needle position raised or lowered). IN the seam Resetting the bobbin stitch counter The defined maximum s.p.m. of the bobbin used is reset to the starting value. Thread clamp Function active or inactive. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 58 Half stitches are performed when the button is pressed (needle position raised or lowered). IN the seam Resetting the bobbin stitch counter The defined maximum s.p.m. of the bobbin used is reset to the starting value. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 59: Setting The Speed Parameter (Max Speed)

    Setting the Thread cutter parameter (Thread Trim) Set whether the thread cutter is activated or deactivated at the end of the seam. Menu item Setting option (Thread Trim) ON = on Thread cutter OFF = off Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 60: Setting The Thread Clamp Parameter (Thread Clamp)

    Initial alignment stitch function 5.4.6 Setting the Start bartack parameter (Start Tack) There are various options for setting the start bartack. All subitems in the Start Tack menu are listed in the following table. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 61 Value range Speed Speed in bartack 0000 – 2000 ON/OFF Pedal Stop, Single stitches per pedal  p. 61 ON/OFF Value range Thr.Tens.Def, Default needle thread 01 - 99 tension  p. 61 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 62 If this function is active, the same stitch length is used for the bartack as the one set in Manual mode. If this function is deacti- vated, a custom input can be entered. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 63 This function is useful for the short stitch for the short thread cutter, for example. In this case, one less stitch is sewn in the last section. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 64: Setting The End Bartack Parameter (End Tack)

     p. 60 ON/OFF St.Len.Def., Default stitch length St.Len. (↑) Value range  p. 60 01.0 – 12.0 [mm] (depending on subclass) St.Len. (↓) Value range 01.0 – 12.0 [mm] (depending on subclass) Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 65 01 - 50  p. 61 ON/OFF Last Repeti., Number of stitches Stitches (↑/↓) Value range different for last 01 - 50 section  p. 61 ON/OFF Invert Dir., Invert direction  p. 62 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 66: Setting The Sewing Foot Lift Parameter (Foot)

    Value range 00 – 20 [mm] FL ht.AtStop, High sewing foot lift (depending on subclass) when sewing stops Value range 00 – 20 [mm] FL ht.A.Trim, High sewing foot lift (depending on subclass) after thread cutting Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 67: Setting The Bobbin Monitor Parameter (Bobbin)

    Value range 0000 – 5000 [ms] Monitor, t Clean  p. 66 ON/OFF Motor Stop A/B/C/D Softw., Counter type Software Value range 00000 – 99999  p. 66 Counter ON/OFF Motor Stop ON/OFF ResetNeces Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 68 LEDs on the machine arm give a warning if the bobbin is empty. It is only possible to resume sewing after ResetNeces ON/OFF changing the bobbin and confirming the message on the control panel. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 69: Setting The Information Parameter (Infoscreen)

    Meaning no display Bobbin stitch counter Bobbin Cnt Current speed Speed Handwheel position Position (Value range 000 – 359 [°]) Material thickness detection Mat.Thickness Pedal position Pedal (Value range 24 – -2) Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 70: Setting The Puller Parameter (Puller)

    2 distance. Menu item Setting option Value range 01.0 – 45.0 [mm] Distance Edge guide Value range 01.0 – 45.0 [mm] Gap (+) Edge stop 2 Distance Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 71: Setting The Correction Of Effects Of High Speed (Speed Corr.) Parameter

    Needle thread linear Thr.Tens. tension  p. 72 Min. Speed Max. Speed 2.OnOff Min. Speed 2.On Min. Speed Foot Press., Sewing foot linear Foot Press. pressure  p. 72 Min. Speed Max. Speed Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 72 DOES NOT switch to the base value for the parameter. Only after finishing the seam by cutting the thread is the base value for the parameter set again. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 73 0000 – 4000 [rpm] (depending on subclass) Speed from which the 2 stitch 2.On Min. Speed Value range length should be used. 0000 – 4000 [rpm] (depending on subclass) Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 74 0000 – 4000 [rpm] should start. (depending on subclass) Speed up to which the Max. Speed Value range increase in sewing foot 0000 – 4000 [rpm] pressure should occur. (depending on subclass) Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 75: Setting The Material Thickness Detection (Fabricthickness) Parameter

    2.OnOff ThickMin 2.On ThickMin Stitchlen.,  p. 76 linear Stitch length ThickMin ThickMax 2.OnOff ThickMin 2.On ThickMin Thr.Tens., Needle thread linear Thr.Tens. tension  p. 77 ThickMin ThickMax 2.OnOff ThickMin 2.On ThickMin Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 76 DOES NOT switch to the base value for the parameter. Only after finishing the seam by cutting the thread is the base value for the parameter set again. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 77 Value range 00.0 – 10.0 [mm] which the 2 sewing foot stroke should be used. Material thickness from 2.On ThickMax Value range 00.0 – 10.0 [mm] which the 2 sewing foot stroke should be used. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 78 Value range 00.0 – 10.0 [mm] which the 2 stitch length should be used. Material thickness from 2.On ThickMin Value range 00.0 – 10.0 [mm] which the 2 stitch length should be used. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 79 Value range 00.0 – 10.0 [mm] the increase in sewing foot pressure should start. Material thickness up to ThickMax Value range 00.0 – 10.0 [mm] which the increase in sewing foot pressure should occur. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 80: Setting The Light Barrier (Lightbarrier) Parameter

    The signal scan of the light barrier is performed at the end of the seam. If the function is active, the machine will continue to sew with the specifically set parameters following the signal detection. If the function is inactive, nothing will happen. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 81: Setting The Outputs Parameter (Output)

    Technician level. This requires that the parameter Add I/O be configured at the Technician level; for more details, refer to the explanation in the  Service Instructions. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 82: Using Automatic Mode

    0 – 9 and confirm with the OK button If you select program 000, the control selects Manual mode,  p. 50. Seam sections Number of seam sections contained in the current program. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 83: Sewing In Automatic Mode

    The number under the current seam section shows the number of stitches yet to be sewn / the outstanding length of the seam section. The program bar shows half the current seam section in bold. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 84 Technician level. The s.p.m. option is set at the factory. Stop at the end of the seam section with thread cutting Switch between two seam sections without stopping Switch between two seam sections, with a stop, but without thread cutting Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 85: Canceling A Program In Automatic Mode

    To cancel the program completely, press the pedal all the way backwards again.  The program is canceled, and the machine starts from the first seam section in the program when sewing resumes. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 86: Using Programming/Edit Mode

    Fig. 37: Programming mode display Programming mode offers two options for creating new seam programs: • Creating a program using keyboard input,  p. 85. • Creating a program using teach-in,  p. 87. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 87: Creating A Program Using Keyboard Input

    Stitch length for the current seam section Value range: 00.0 - 12.0 [mm] (depending on the subclass) • Use ◄/► to select the Stitch length parameter • Use ▲/▼ to change the stitch length Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 88 Repeat steps 6 and 7 to define up to 30 seam sections if necessary. Press the ESC button.  The program is saved. The machine switches to Automatic mode and the newly created program is selected. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 89: Creating A Program Using Teach-In

    • Use ▲/▼ to select the right or the left needle thread • Press the OK button to confirm • Use ▲/▼ to change the needle thread tension • Press the OK button to confirm Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 90: Adjusting Parameters For The Current Seam Section

    NOT the entire program. To adjust the parameters for the current seam section: ◄/► to select the field Press the OK button.  The submenu opens. ▲/▼ to select the desired parameter. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 91 End bartack, setting identical to Manual mode,  p. 62. Needle Up Position of the needle when sewing stops on the seam section. Foot Lifted Position of the sewing foot when sewing stops on the seam section. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 92: Adjusting Parameters For The Selected Program

    5.6.5 Adjusting parameters for the selected program This menu allows the parameters for the current program/seam program to be changed. This setting affects all seam sections created in the program. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 93 Press the OK button to activate or deactivate the parameter ▲/▼ or use to edit the value and confirm the change by press- ing the OK button. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 94 Daily piece counter, can be set to count either up or down. When the daily piece counter is activated, it must be reset once after entering a value using the function in the softkey menu to ensure it counts correctly. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 95: Editing Programs

    Press the P button.  The control switches to Edit mode. The following information is shown, and the P in the program number field flashes: Fig. 40: Display in editing mode 5 2.0 Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 96: Copying The Program

     The P above the program number will flash. Press the Softkey menu button.  The softkey menu appears. Fig. 41: Softkey menu Press the numeric button under  The following display appears: Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 97 5 2.0 If necessary, make changes to the newly copied program. Press the ESC button.  The program is saved. The machine switches to Automatic mode and the newly created program is selected. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 98: Deleting The Program

    ▲/▼ To delete further programs, select the program using repeat from step 3. Press the ESC button to go to Automatic mode.  The machine switches to Automatic mode. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 99: Maintenance

    Advanced maintenance work may only be carried out by qualified specialists ( Service Instructions). Maintenance intervals Work to be carried out Operating hours Cleaning  Removing lint and thread remnants Lubricating  Lubricating the machine head  Lubricating the hook Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 100: Cleaning

    Lint and thread remnants can impair the operation of the machine. Clean the machine as described. NOTICE Property damage from solvent-based cleaners! Solvent-based cleaners will damage paintwork. Use only solvent-free substances for cleaning. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 101 • Area under the throat plate (4) • Hook (2) • Area around the needle (1) To clean the machine: Switch off the machine. Remove any lint and thread remnants using a compressed air gun or a brush. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 102: Lubricating

    For topping off the oil reservoir, use only lubricating oil DA 10 or oil of equivalent quality with the following specifications: • Viscosity at 40 °C:10 mm • Flash point: 150 °C Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 103: Checking The Machine Head Lubrication

    If the inspection glass lights up red, the machine is not suffi- ciently supplied with oil. If the oil level is below the minimum level marking (3): Pour oil through the refill opening (1) but no higher than the maximum level marking (2). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 104: Checking The Hook Lubrication

    10 seconds with the sewing feet lifted and at a high speed.  The blotting paper will show a thin strip of oil when sewing is complete. Fig. 47: Lubricating the hook ① (1) - Screw Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 105: Servicing The Pneumatic System

    Refer to the Technical data ( p. 139) chapter for the permissi- ble operating pressure. The operating pressure cannot deviate by more than ± 0.5 bar. Check the operating pressure on a daily basis. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 106 Turn the pressure controller until the pressure gage (2) indi- cates the proper setting: • Increase pressure = turn clockwise • Reduce pressure = turn counterclockwise Push the pressure controller (1) down. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 107: Draining The Water Condensation

    (1) - Filter element (3) - Drain screw (2) - Water separator To drain water condensation: Disconnect the machine from the compressed air supply. Place the collection tray under the drain screw (3). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 108: Cleaning The Filter Element

    Solvent-based cleaners damage the filter. Use only solvent-free substances for washing out the filter tray. Fig. 50: Cleaning the filter element ① ③ ② (1) - Filter element (3) - Drain screw (2) - Water separator Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 109: Parts List

    Tighten the drain screw (3). 10. Connect the machine to the compressed air supply. Parts list A parts list can be ordered from Dürkopp Adler. Or visit our website for further information at: www.duerkopp-adler.com Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 110 Maintenance Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 111: Setup

    Remove all transport locks before setting up the machine: • Lashing straps and wooden blocks from the machine head, the table and the stand • Supporting wedges between machine arm and throat plate Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 112: Assembling The Stand

    Tighten the inner bars (1) down so that both head sections (8) are at the same height. Important Turn the adjusting screw (3) so that the stand has even contact with the ground. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 113: Assembling The Pedal And Setpoint Device

    Attach the pedal rod (1) with the ball sockets to the setpoint device (5) and to the pedal (4). Pull the pedal rod (1) to the correct length: Proper setting 10° inclination with pedal (4) released Tighten the screw (2). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 114: Tabletop

    (6) - Hole (3) - Drawer (7) - Reel stand (4) - Oil pan To complete the tabletop: Screw the drawer (3) with the left-hand bracket to the under- side of the tabletop. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 115: Assembling The Tabletop To The Stand

    To assemble the tabletop to the stand: Place the tabletop on the head sections (1) of the inner bars. Use the screws (2) to fasten the tabletop at the screw holes of the head sections. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 116: Setting The Working Height

    The working height is continuously adjustable between 750 and 900 mm (clearance between the floor and upper edge of the tabletop). Fig. 55: Setting the working height ① (1) - Screws Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 117: Assembling The Control

    Screw the control (2) onto the 4 screw holders (3) under the tabletop. Clamp the power cable of the control (2) into the strain relief mechanism (1). Screw the strain relief mechanism (1) under the tabletop. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 118: Inserting The Machine Head

    Always lay the cables so as not to create any chafing or pinching points. Fig. 57: Inserting the machine head ② ① (1) - Rubber inlays (2) - Upper hinge parts Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 119 If not already assembled, the permanent magnet must be screwed to the tabletop. In this case, the permanent magnet will be included in the acces- sory pack of the machine. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 120: Assembling The Control Panel

    (2) - Plug To assemble the control panel: Tighten the control panel (1) on the bracket (3). Insert the plug (2) of the connecting cable into the socket of the control panel (1). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 121: Assembling The Knee Button

    Guide the connecting cable (2) to the back between the oil pan and the control. Insert the plug (3) of the connecting cable into the socket of the control. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 122: Electrical Connection

    When the machine is switched off at the main switch, the supply voltage for the sewing lamp remains active. Disconnect the power plug before assembling the sewing lamp with sewing lamp transformer. Ensure the power plug cannot be unintentionally reinserted. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 123 Screw the sewing lamp transformer (1) in place at the pre-drilled holes under the tabletop. Assemble the connecting cable under the tabletop using cable ties. Establish the plug connection to the supply line for the sewing lamp. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 124 Loosen the adapter cover screws (2). Connect the supply line: • for additional sewing lamps to be assembled to the X3 connection (5) • for integrated LED sewing lamps connected to the 24V/X5 connection (4) Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 125: Establishing Equipotential Bonding

    Feed the equipotential bonding cable from the connection (1) on the rear side of the control through the slot in the tabletop and plug it onto the tab connector (2) on the base plate. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 126: Connecting The Control

    Disconnect the power plug before connecting the control. Ensure the power plug cannot be unintentionally reinserted. To connect the control: Connect the control as specified in the wiring diagram ( p. 141). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 127: Pneumatic Connection (Optional)

    The pneumatic connection package is available under part num- ber 0797 003031. It consists of: • System connection hose (length 5 m, diameter 9 mm) • Hose connectors and hose clamps • Coupling socket and coupling plug Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 128: Assembling The Compressed Air Maintenance Unit

    Connect the machine hose (4) coming out of the machine head to the maintenance unit (3) at the top right. Connect the system connection hose (2) to the pneumatic system. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 129: Setting The Operating Pressure

    ± 0.5 bar. Fig. 64: Setting the operating pressure ① ② (1) - Pressure controller (2) - Pressure gage To set the operating pressure: Pull the pressure controller (1) up. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 130: Checking The Lubrication

    Check at the inspection glass (3) whether the warning indica- tor is lit red or the oil level has dropped below the minimum marking (1). If this is the case, top off oil ( p. 101). Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 131: Performing A Test Run

    11. Transfer the desired quick function from the push button to the favorite button ( p. 41). 12. Start the sewing test at low speed. 13. Gradually increase the speed until the working speed is reached. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 132 Setup Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 133: Decommissioning

    Remove residual oil from the oil pan using a cloth. Cover the control panel to protect it from soiling. Cover the control to protect it from soiling. Cover the entire machine if possible to protect it from contam- ination and damage. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 134 Decommissioning Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 135: Disposal

    When disposing of the machine, be aware that it consists of a range of different materials (steel, plastic, electronic components, etc.). Follow the national regulations when disposing these materials. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 136 Disposal Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 137: Troubleshooting

    Email: service@duerkopp-adler.com Internet: www.duerkopp-adler.com 10.2 Messages of the software Should a fault occur, refer to the  Service Instructions or turn to Customer Service. Do not attempt to correct the error yourself. Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 138: Errors In Sewing Process

    ( p. 32). Thread-guiding parts, such Check threading path as thread guides, are ( p. 24). sharp-edged Throat plate or hook have Have parts reworked by been damaged by the qualified specialists needle Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 139 ( p. 24,  p. 31). thread have not been threaded correctly Needle Needle thickness is Use recommended needle breakage unsuitable for the sewing thickness ( p. 139). material or the thread Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 140 Troubleshooting Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 141: Technical Data

    Speed on delivery 3000 [min Mains voltage 230 V Mains frequency [Hz] 50/60 Operating pressure [bar] (Compressed air only required in combination with optional additional equipment) Length [mm] Width [mm] Height [mm] Weight [kg] Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 142 30 individual seam sections each • Sequential mode for a maximum of 9 interlinked seam programs • Service button for service routines with the sewing motor switched off Operating Instructions 667 PREMIUM - 02.0 - 01/2018...

  • Page 143: Appendix

    Appendix 12 Appendix Fig. 66: Tabletop drawing Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 144 Appendix Operating Instructions 667 PREMIUM - 02.0 - 01/2018...
  • Page 146 DÜRKOPP ADLER AG Potsdamer Str. 190 33719 Bielefeld Germany Phone: +49 (0) 521 925 00 Email: service@duerkopp-adler.com www.duerkopp-adler.com...

Table of Contents
