9 Data Services - Classical IP & IP Routing
The 'CIP Connections'
table
'CIP Connections' table
components
166 / 362
The following figure shows the 'CIP Connections' table:
The following fields are shown:
Field Description
Dest Indicates the CIP VC phonebook name.
Remote IP Indicates the remote IP address of the remote ADSL side of
Address the LIS, i.e. the IP address of the remote CIP interface.
Note: In case the VC is not cross connected, or implicit
assignment was not successful, this field shows Unresolved".
Action This field contains one of the two following action buttons:
Button Action
Add a CIP connection to the list.
Delete an existing connection from the
list.
