9 Data Services - Classical IP & IP Routing
9.2.3

Implicit Assignment Mechanism

Implicit assignment
Implicit assignment
example
Note
154 / 362
If the remote side is RFC1577 compliant, e.g. another
STWireless, your local STWireless is able to retrieve the remote
IP address of the CIP PVC, by issuing an InATMARP request on that
PVC.
That way, you must not specify an IP address for the CIP PVCs you
add to the 'CIP Connections' table, it will be implicitly assigned
when connecting to the LIS.
The sequence below describes an example of an implicit
assignment mechanism:
Phase Decision and Description
1 Suppose you added a CIPPVC without supplying an IP address (e.g.
CIPPVC2).
2 The STWireless will automatically issue an InATMARP request on
this PVC.
3 Is the remote side is RFC1577 compliant ?
4 It responds with an InATMARP
reply, containing its IP address.
The CIP's remote IP address in the
'CIP Connections'
completed.
5 Does the remote address share a
LIS with a local CIP member ?
Yes
6 the CIPPVC is
assigned to this
member.
Connectivity is
assured.
The grey shaded area of the table indicates the sequence of a
correct RFC1577 compliant LIS interconnection.
Yes
"Unresolved" will show up in the
'Remote IP Address' field.
Consequently the CIPPVC cannot
table is be assigned and IP connectivity
will not exist with the remote
machine.
No
"Unresolved"
will show up.
No connectivity
exists.
No
hi
