9 Data Services - Classical IP & IP Routing
9.2.1

General CIP Configuration Procedure

Decision procedure
152 / 362
Due to the many decisions that must be made in order to be able
to configure the STWireless to be an active member of a LIS, the
procedure to be followed is best retrieved from the following
decision table:
Step Decision and/or Action
Are you configuring the STWireless for an existing LIS ?
1
Answer Action and Description
Yes You must retrieve the LIS IP parameters to
which your local configuration must adhere
to. See topic 'Configuration for an Existing LIS'
of subsection 9.2.2.
No You can create the LIS with IP parameters of
your choice. See topic 'Creating a New LIS' of
subsection 9.2.2.
In case you create a new LIS, you must create
the LIS at both end of the ADSL connection, i.e.
at the local, and on the remote side.
2 Retrieve the appropriate LIS parameters, and check on
which VCs (identifiable by their VPI/VCI values) your service
provider enabled the CIP packet service.
3 If needed, create a CIP phonebook entry, i.e. a CIP PVC, in
the 'Phonebook' web page.
Is the remote access router a RFC1577 compliant device,
4
e.g. another STWireless?
Answer Action and Description
Yes The remote access router will respond to
'InATMARP' requests, thus the CIP PVC can be
implicitly assigned to the CIP member.
The remote access router will not respond to
No
'InATMARP' requests submitted by the
STWireless, thus the CIP PVC must be explicitly
assigned to the CIP member.
5 If needed, create a CIP member in the 'CIP Interfaces' table
of the 'CIP' web page.
6 Add appropriate IP routes to the STWireless via the 'IP
route' table on the 'Routing' web page.
7 Add appropriate IP routes in you PC(s).
See
9.2.2
9.2.2
9.4
See
9.2.3
9.2.4
9.4
9.2.6
9.2.6
