Page 1: Quick Start Guide
ADSL-DMT Router Quick Start Guide P/N 3EC 16964 AAAA-AAZZA... - Page 2 First Edition (October 1999) COPYRIGHT Alcatel provides this publication “as is” without warranty of any kind, either express or implied, including, but not limited to, the implied warran- ties of merchantability or fitness for a particular purpose. All rights reserved. No part of this book may be reproduced in any form or by any means without written permission from Alcatel.
-
Page 3: Table Of Contents
CONTENTS Introduction....................3 Getting Started .....................5 STEP 1. Inspect Box Contents..............5 STEP 2. Connect the Router ................7 STEP 3. Check TCP/IP ................9 STEP 4. Open Browser to Run Easy ............12 STEP 5. Verify Network Service Provider Connection ......21... - Page 4 Other Useful Information Router FAQs ....................22 Glossary .....................25 IP Address Reference Map ................35 Command Line Interface Overview ............36 Speed Touch Office Software Specifications..........39 Speed Touch Office Hardware Specifications ...........42...
-
Page 5: Introduction
INTRODUCTION ! ! ! ! What is Easy Setup? Easy Setup is a web browser-based software program that allows you to configure your router quickly and easily, even if you have never installed a router before. If a qualified technician from your Network Service Provider (NSP) has already installed your router, you don’t need to run the Easy Setup pro- gram. - Page 6 The Easy Setup program permanently resides inside your router, allowing you to configure it through a web browser on any platform – Windows, Macintosh, or Unix. If you are configuring your router in Windows, you have the option of installing the Speed Touch™ Office Manager Tools from the Installation CD.
-
Page 7: Getting Started
Getting Started Establishing a high-speed ADSL connection with your Speed Touch Office router should only take a few minutes if you follow the 5 easy steps below. While you have many installation options, the items that you don’t want to overlook have been highlighted for your convenience. - Page 8 You should also have a list from your NSP with the following information: Protocol to use: PPP (Point-to-Point Protocol, requires a User Name and Password) or RFC 1483 (SNAP Encapsulation) or RFC 1483MER (MAC Encapsulated Routing, requires a WAN Gateway address) Network option to use Bridging and/or IP Routing (requires a WAN IP address and Subnet Mask)
-
Page 9: Step 2. Connect The Router
STEP 2. Connect the Router To extend the lifetime of your router, place it in a location where it will be well ventilated. Never stack it with other devices on carpet. A diagram of the router’s rear panel, showing a power switch and cables ports, appears on the next page. - Page 10 Alternatively, you may connect a PC via a hub to the router using a cross- over cable (yellow label). If the hub port being connected to the router hap- pens to be a crossover or uplink port (labeled X), you will need to use the straight-through cable (red label).
-
Page 11: Step 3. Check Tcp/Ip
STEP 3. Check TCP/IP If you have connected your router to a Windows platform, you can verify that TCP/IP is running by clicking the Start button, then Settings, Control Panel, and finally the Network icon in the Control Panel Window. The Network window now appears. - Page 12 In the TCP/IP Properties window, set your PC to obtain an IP address automatically. If TCP/IP is missing, consult your windows documentation to install this driver.
- Page 13 If you have connected your router to a Macintosh platform, you can verify that TCP/IP is running by clicking the Apple icon, then Control Panels, and TCP/IP. In the TCP/IP window, set your PC to Configure Using DHCP Server.
-
Page 14: Step 4. Open Browser To Run Easy
STEP 4. Open Browser to Run Easy Setup Open your browser and enter your router’s default Ethernet address 192.168.254.254 in the URL (“Location” or “Address” bar). Press Enter on your keyboard. After a connection is made with the router, a screen will appear requesting a User Name and Password. - Page 15 Now you will see a screen describing some of your router’s features and settings. Click on Easy Setup, which will take you to the next page. You will see that some basic functions and benefits are described in the left margin of each Easy Setup window.
- Page 16 Please note that resizing your browser window either vertically or horizon- tally will change the appearance of Easy Setup pages, hence it’s possible that the Easy Setup pages on your PC screen will appear to be slightly dif- ferent from those in this guide. The first Easy Setup page requests WAN information.
- Page 17 If you selected PPP as your WAN protocol, a page requesting a User Name and Password will appear. You also need to select networking options. If your NSP has not suggested specific parameters and you’re not sure what’s appropriate, choose IP routing with NAT enabled. Click on Next to continue.
- Page 18 If you selected RFC 1483 as your WAN protocol, you need to select net- working options. If your NSP has not suggested specific parameters and you’re not sure what’s appropriate, choose IP routing, Obtain configura- tion automatically from WAN, and NAT enabled. Click on Next to con- tinue.
- Page 19 If you selected RFC 1483 MER as your WAN protocol, you need to select networking options. If your NSP has not suggested specific parameters and you’re not sure what’s appropriate, choose IP routing, Obtain config- uration automatically from WAN, and NAT enabled. Click on Next to continue.
- Page 20 You may enable DHCP on the next page that appears. You must also spec- ify if DNS information should be obtained automatically or configured manually. If manually configuring, you need to enter at least 1 DNS IP address. Click Next to continue.
- Page 21 On the LAN page you must enter the LAN IP address and subnet mask. IPX configuration is another option. Click Save to return to the main Easy Setup window.
- Page 22 It is strongly recommended that you change the default Password before exiting this program. You must enter it twice. If you incorrectly enter one word, a message will appear requesting that you reenter the password. You must click Reboot Router on the Router Information page for the changes to take effect.
-
Page 23: Step 5. Verify Network Service Provider Connection
STEP 5. Verify NSP Connection If you have connected all the cables properly and entered appropriate val- ues in Easy Setup, the router’s Link LED should appear solid green now. To verify that your DSL connection has been established, enter a web site address in the URL bar and press Enter. -
Page 24: Router Faqs
Router FAQs Which cable do I use to connect a new LAN device to the router? If you are directly connecting your PC to the router’s built-in Ethernet hub, then use the straight-through (red label) cable. If you are connecting your router to another hub, then use the crossover (yellow label) cable, unless the LAN hub has a built-in crossover or uplink port, in which case you should use the straight-through (red label) cable. - Page 25 What kind of security options do I have? NAT (Network Address Translation) with “IP masquerading” can provide a level of “security by obscurity” that is acceptable to many users. It can block incoming connections to LAN workstations by hiding them behind the router’s single IP address.
- Page 26 What is MER? MER (MAC Encapsulated Routing) allows your router to route on the LAN side and bridge on the WAN side. MER is only needed when your NSP doesn’t support routing. MER adds NAT functionality, providing greater security and more IP addresses than your NSP provided for your LAN workstations.
-
Page 27: Glossary
Glossary This glossary covers some of the networking terms that you are likely to encounter while learning about your high-speed ADSL connection. You may also want to consult one of the commercially available telecom dictionaries that provide greater information. If you have technical support questions and can’t find the answers in this glossary or another section of the Quick Start Guide, please check the CLI reference manual. - Page 28 backbone - A backbone describes a high bandwidth cable to which multiple networks are connected in order to minimize traffic between them. bandwidth - Bandwidth is the capacity to handle simultaneous data transmissions -- the greater the bandwidth, the more information that can be sent in a given amount of time.
- Page 29 DHCP - Dynamic Host Configuration Protocol allocates IP addresses automatically to any DHCP client, that is, any device on your LAN requesting one. It eliminates the need for manual configuration of each device. Your router can also act as a DHCP client to collect network-addressing information from a DHCP server at another site for your LAN.
- Page 30 filter - Generally this is a process or device that screens network traffic for characteristics such as source address, destination address, or protocol, and determines whether to forward or block traffic based on the criteria that you have programmed. firewall - This IP filtering security software can render parts of the LAN inaccessible and invisible to the public.
- Page 31 identity as well as the integrity of data, encryption (ESP) to protect the privacy of data, and access control through key exchange (IKE). IPX - Internetwork Packet Exchange is a NetWare (Layer 3) protocol used for transferring data from servers to workstations. IPX is similar to IP. L2TP - Layer 2 Tunneling Protocol supports the creation of a VPN over the Internet.
- Page 32 metric - A metric is an algorithm used by routers to determine the best path for sending packets to a remote destination. NAT - Network Address Translation allows multiple workstations on your LAN to share a single high-speed Internet connection. All outgoing traffic appears to originate from the router’s IP address.
- Page 33 packet - It is the standard unit of data sent across networks. It contains a header with control information and raw user data sometimes called a “payload”. ping - Packet INternet Grouper is an Internet program used to determine whether a specific address is accessible.
- Page 34 RFC 1483 - RFC 1483 SubNetwork Access Protocol (SNAP) is a standard method for encapsulating multiprotocol data into frames for ATM (OSI Layer 5) networks. It is one of many RFC “link protocols” that define how different devices communicate with each other across networks and assure “interoperability”. RIP - Routing Information Protocol helps keep routing tables current so that IP traffic passes efficiently from source to destination.
- Page 35 stack - A stack is a set of related communications protocols that operate together to facilitate communication at some or all of the 7 layers of a standard network. TCP/IP is one example of a protocol stack. subnet mask - This 32-bit address mask is required in IP routing and is usually supplied by your NSP.
- Page 36 twisted pair - This refers to a transmission medium consisting of two insulated copper wires arranged in a regular spiral pattern. The wires can be shielded or unshielded. Twisted pair is common in telephony applications and is increasingly common in data networks. UNIX - UNIX is an operating system that was developed in 1969 at Bell Laboratories.
-
Page 37: Ip Address Reference Map
IP Address Reference Map If this is the first time you’ve set up a router, you may be wondering why the router needs to be configured with so many different IP addresses. An example of how some logical IP addresses might be associated with physi- cal nodes is presented below. -
Page 38: Command Line Interface Overview
Command Line Overview The Command Line Interface reference manual covers the following advanced configuration topics: • How to set names, passwords, PVC numbers, and link and network parameters • How to configure specific details within a protocol, such as IP or IPX addresses and IP protocol controls •... -
Page 39: Accessing The Command Line Interface
• Configure NAT • Configure Telnet/SNMP security • Configure host mapping • Configure IP multicast • Execute script files • Configure encryption • Configure IP filtering • Configure L2TP filtering • Install software option key Accessing the Command Line Interface The console port may be used to access the Command Line Interface (CLI). - Page 40 Windows platforms: To open the HyperTerminal emulator available in Windows, click Start on your desktop, select Programs, Accessories, and HyperTerminal. Hypertrm.exe. Enter a name for the connection in Connection Description. In the Phone Number window, under Connect using, select Choose Direct to Com 1 (or 2) in the properties page.
-
Page 41: Speed Touch Office Software Specifications
Speed Touch™ Office ADSL-DMT Router Software Specifications Routing TCP/IP with RIP 1 (RFC 1058), RIP1-compatible and RIP2 (RFC 1389), or routing on the LAN and/or WAN Novell® IPX with RIP/SAP (RFC 1552) DHCP Server – Automatic assignment of IP address, mask, default gateway, and DNS servers’... -
Page 42: Ip Address Translation
Spoofing filtering (IP-RIP, IPX-RIP, SAP, Watchdog, serialization) Automatic IP and DNS assignment (RFC 1877) IP Address Translation Network renumbering (RFC 1631) Network Address Translation (NAT/PAT) LAN servers supported with NAT Configuration Management Easy Setup web browser-based GUI Windows Quick Start program for easy setup Administration through SNMP, Telnet, or VT100 terminal TFTP download/upload of new software, configuration files, and scripts Performance monitor for Windows... - Page 43 Encapsulation (IP, Bridging, and Encapsulated Routing) (RFC 1483) PPP over ATM (LCC and VC multiplexing) (RFC 2364) Classical IP (RFC 1577) AAL5 Multiple Virtual Cicuits (VCs) Virtual circuit (VC) traffic shaping (UBR, VBR, CBR) 1.610 OAM F5 LoopBack Security User authentication (PAP/CHAP) with PPP (RFC 1334, RFC 1994) Password control for Configuration Manager SNMP community name reassignment Telnet/SNMP port management...
-
Page 44: Speed Touch Office Hardware Specifications
Speed Touch™ Office ADSL-DMT Router Hardware Specifications WAN Interface One Asymmetrical Digital Subscriber Line (ADSL) WAN interface (RJ-14) RJ-14 Line A/Line B Pinning: 2/5 or 3/4 LAN Interface Built-in 4-port Ethernet hub (4 RJ-45s) LAN speed of up to 10 Mbps ADSL Modem Specifications Up to 8 Mbps downstream Up to 1 Mbps upstream... -
Page 45: Physical Specifications
Physical Specifications Dimensions: 8.4 W x 7.0 D x 1.7 H inches 21.3 W x 17.8 D x 4.3 H cm Weight: 1.5 lbs. (.68 Kg.) Operating Environment Temperature: 40°F to 105°F (5°C to 40°C) Humidity: 20%-80%, non-condensing Power Requirements AC Voltage: 100 to 120 VAC, 220 to 240 VAC Frequency: 50/60 Hz Power Consumption: 10 W maximum... -
Page 46: Front Panel Leds
Front Panel LEDs Six LEDs indicating router activity appear on the front left of the router. The table below describes what the different colors indicate. Indicator Description Green: Power is applied Off: Power is not applied Amber: Running router power-on self-test TEST Green: Router power-on self-test successful... - Page 47 Rear Panel Power and Connections The rear panel contains all DSL, Ethernet, console, and power interfaces. From left to right: Power The router has an ON/OFF switch labeled I/O and uses a standard AC power cord. DSL WAN Connection Connectivity to a DSL network is through a 6-pin RJ-14 port. Ethernet LAN Connection The router has a built-in hub with 4 Ethernet 10Base-T ports (8-pin RJ-45).
-
Page 48: Port Descriptions
Port Descriptions ADSL-DMT Port Model 3EC 18208AC All Other Models and 3EC 18238AC Signal Name Signal Name Number Number Not connected Not connected Tip or Line A Not connected Not connected Tip or Line A Not connected Ring or Line B Ring or Line B Not connected Not connected... - Page 49 Console Port Signal Name Number Receive data Request to send Not connected Transmit data Ground Clear to send Not connected Ring indicator...
-
Page 50: Fcc Part 15 Class B Statement
FCC Part 15 CLASS B Statement Section 15.105(b) of the Code of Federal Regulations: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant of Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 51 Canadian D.O.C. Notice This product conforms to Canadian Class B emissions regulations. Ce produit se conforme aux réglements d’émission canadienne classe B. Instructions for Trained Service Personnel Only Caution: Danger of explosion if battery is incorrectly placed. Replace only with the same or equivalent type recommended by the manufacturer.
