5. Connect the GND wire of the flat ribbon cable into the GND screw terminal of the
relay board. For example bellow it is shown 8 channel relay board. The same is
for the rest relay boards.
Figure 25. Connecting the GND wire to the relay board
6. Connecting power supply
Figure 26. Plug the power supply jack into DAEnetIP2
DAEnetIP2 User Manual
12 Sep 2013
-35-
