5.2. DAEnetIP2 ports description
Port JP3 (P3)
digital outputs
Pin N Bit Func
1 1 Free
2 2 Free
3 3 Free
4 4 Free
5 5 Free
6 6 Free
7 7 Free
8 8 Free
9 - GND
10 - GND
Pin N Bit
1
2
3
4
5
6
7
8
9
10
Legend:
• "Free" – the pin is free to be used by user.
• "XXXXXX" - the pin is reserved for special function – can not be accessed.
• "In" – the pin is digital input
• "Out" – the pin is digital output
• "I/O" – the pin is digital input or output depending the settings
• "Ain" – analog input
Port JP4 (P5)
digital outputs
Dir Bit
I/O 1
I/O 2
I/O 3
I/O 4
I/O 5
I/O 6
I/O 7
I/O 8
PWR -
PWR -
DAEnetIP2 System Port JP6 (reserved, not used)
-
-
-
-
-
-
-
-
-
-
Func Dir Bit
Free I/O 1
Free I/O 2
Free I/O 3
Free I/O 4
Free I/O 5
Free I/O 6
Free I/O 7
Free I/O 8
+3.3V PWR
GND PWR
FUNC
+3.3V
+3.3V
Reserved
Ping Led
Reserved
Target RST
Reserved
Reserved
Reserved
GND
