7. SNMP access

DAEnetIP2 supports SNMPv1 protocol – snmpget and snmpset. It may be
configured/read all the parameters via these commands. Read-only community string
is used for reading and Read-Write Community String is used for changing the
parameters. Note that it is not possible using of snmpwalk. Parameters that can be
changed, are grouped according to their functions in the tables below. To obtain a
valid OID number it is necessary to replace the "x" symbol with the prefix
".1.3.6.1.4.1.19865". Also all the snmp commands are described in the
the functions can be accessed via SNMP and WEB
IMPORTANT! During SNMP access, it must be used snmpget and snmpset only to one OID and not
to group of OIDs. Other commands (snmpwalk for instance) are not supported.
NOTE! Because of the specific of the SNMP protocol supported by DAEnetIP2 (it is not possible to
access several OIDs), the initial setting of IP/MASK/Gateway must be done via Web. Otherwise the
DAEnetIP2 module may become not reachable, because of the limitation of only one OID accessing
per a time via snmp.
7.1. Configuration settings
OID Name
x.1.1.1.0 cfgIP
x.1.1.2.0 cfgMAC
x.1.1.3.0 cfgVLANTag
x.1.1.4.0 cfgPassword
x.1.1.5.0 cfgMACLock1
x.1.1.6.0 cfgMACLock2
x.1.1.7.0 cfgPingTime
x.1.1.8.0 cfgVersion
x.1.1.9.0 cfgMode
Access
read-write IP Address of
DAEnetIP2 module
read-only MAC address of
DAEnetIP2 module
read-write VLAN ID (12bit) in
VLANEnabled mode
read-write Read-Write community
string (password)
read-write MAC address of first
remote machine allowed
to access DAEnetIP2
module
read-write MAC address of second
remote machine allowed
to access DAEnetIP2
module
read-write The time (in minutes)
since last ping request
to reboot system and
target
read-only Firmware version,
LSB=VER_MINOR,
MSB=VER_MAJOR
read-write Contains different bit
flags for DAEnetIP2
DAEnetIP2 User Manual
Table 5. Configuration settings
Description
12 Sep 2013
MIB file. All
Syntax
IpAddress
PhysAddress
INTEGER(0..40
95)
OCTET
STRING (SIZE
(4..12))
PhysAddress
PhysAddress
INTEGER(0..25
5)
INTEGER(0..65
535)
INTEGER(0..25
5)
-22-
