7.4. Control ports
OID
x.1.2.1.0 pctrlPort3
x.1.2.2.0 pctrlPort5
x.1.2.3.0 pctrlPort6
7.5. Control port P3 (Digital outputs)
OID
x.1.2.1.1.0 pctrlP3pin1
x.1.2.1.2.0 pctrlP3pin2
x.1.2.1.3.0 pctrlP3pin3
x.1.2.1.4.0 pctrlP3pin4
x.1.2.1.5.0 pctrlP3pin5
x.1.2.1.6.0 pctrlP3pin6
x.1.2.1.7.0 pctrlP3pin7
x.1.2.1.8.0 pctrlP3pin8
x.1.2.1.33.0 pctrlP3byte
7.6. Control port P5 (Digital outputs)
OID Name
x.1.2.2.1.0 pctrlP5pin1
x.1.2.2.2.0 pctrlP5pin2
x.1.2.2.3.0 pctrlP5pin3
x.1.2.2.4.0 pctrlP5pin4
Name Access
read-write
read-write
read-write
Name Access
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
Access
read-write
read-write
read-write
read-write
Description
I/O port data
I/O port data
I/O port data
Description
Port3 pin1 data
Port3 pin2 data
Port3 pin3 data
Port3 pin4 data
Port3 pin5 data
Port3 pin6 data
Port3 pin7 data
Port3 pin8 data
I/O port data as
single byte
Table 10. Control port P5
Description
Port5 pin1 data
Port5 pin2 data
Port5 pin3 data
Port5 pin4 data
DAEnetIP2 User Manual
12 Sep 2013
Table 8. Control ports
Syntax
INTEGER(0..255)
INTEGER(0..255)
INTEGER(0..255)
Table 9. Control port P3
Syntax
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER(0..255)
Syntax
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
