List of measurements managed by UPS. This table is accessible on MODBUS TCP by request-
ing 48 words to address 0x1060.
address CODE DESCRIPTION
0x1060 M00 Load rate phase1
0x1061 M01 Load rate phase 2
0x1062 M02 Load rate phase 3
0x1063 M03 UPS load rate
0x1064 M04 Battery Capacity
0x1065 M05 Battery Capacity
0x1066 M06 Input bypass voltage phase 1
0x1067 M07 Input bypass voltage phase 2
0x1068 M08 Input bypass voltage phase 3
0x1069 M09 Output voltage phase 1
0x106A M10 Output voltage phase 2
0x106B M11 Output voltage phase 3
0x106C M12 Input current L1
0x106D M13 Input current L2
0x106E M14 Input current L3
0x106F M15 Output current phase 1
0x1070 M16 Output current phase 2
0x1071 M17 Output current phase 3
0x1072 M18 Input bypass frequency
0x1073 M19 Output frequency
0x1074 M20 Battery voltage (+)
0x1075 M21 Battery voltage (-)
0x1076 M22 Ambient Temperature
0x1077 M23 Remaining backup time
0x1078 M24 Battery current
0x1079 M25
0x107A M26
0x107B M27
0x107C M28
0x107D M29
0x107E M30
0x107F M31
0x1080 M32
0x1081 M33 Rectifier input voltage phase 1
0x1082 M34 Rectifier input voltage phase 2
0x1083 M35 Rectifier input voltage phase 3
0x1084 M36 UPS output power
0x1085 M37 Output power phase 1
0x1086 M38 Output power phase 2
0x1087 M39 Output power phase 3
76 GB
NETYS/
units format
ITYS
% ### X
%
%
% ### X
% ### X
Ah*10 ###.#
V ### X
V
V
V ### X
V
V
A
A
A
A*10 ###.# X
A*10
A*10
Hz*10 ##.# X
Hz*10 ##.# X
V*10 ###.# X
V*10 ###.# -1
°C ## X
Minutes #### X
A*10 ±###.# -1
V ### X
V
V
kW*10
kVA*10 ###.#
kVA*10
kVA*10
MAS- DELPHYS
TERYS MP/MX
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X -1
X -1
X -1
X X
X X
X X
X X
X X
X X
X -1
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
NET-VISION 7 - SOCOMEC
DELPHYS
BC/GP
X
X
X
X
X
X
X
X
X
X
X
X
-1
-1
-1
X
X
X
X
X
X
-1
X
X
X
X
X
X
-1
X
X
X
