a : Jbusp ups Cross-ref table: netys / itys / masterys / delphys
ppendix
List of status managed by UPS. This table is accessible on MODBUS TCP by requesting 4
words to address 0x1020.
LEVEL
S00 I Rectifier Input supply present
S01 I
S02 I
S03 I Load protected by inverter
S04 W Load on automatic bypass
S05 W on battery / Battery discharging
S06 Remote controls disabled
S07
S08 W Stand-by mode
S09
S10 I Battery test in progress
S11 I Battery test programmed
S12 I Battery test in stand-by
S13 I Battery test supported
S14 W Battery test failed
S15 C Battery near end of backup time
S16 C Battery discharged
S17 I
S18
S19
S20
S21
S22
S23 Inverter synchro with mains
S24
S25
S26 I Bypass input supply present
S27 I Battery charging
S28 Bypass input fr. out of tolerance
S29 Stand-by schedule
S30 UPS on parallel system
S31 Battery extension
S32
S33
S34
S35
S36
S37
S38 External Input 1
S39 External Input 2
S40 External Input 3
S41 External Input 4
S42 Controls permission table managed
S43
S44
S45
S46 I Operating on Gen Set
S47
S48 W Maintenance mode active
S49 W End of the first maintenance period
...
S63
For more information please refer to MODBUS User manual according to the UPS range.
NET-VISION 7 - SOCOMEC
Inverter ON
Rectifier ON
Eco-mode ON
Buzzer on
Battery OK
Boost on
Unit 1 present
Unit 2 present
Unit 3 present
Unit 4 present
Unit 5 present
Unit 6 present
power share
NETYS PR/RT MASTERYS BC/
ITYS GP
X X
X X
X X
X X
X X
X X
X
X X
X X
X X
X X
X
X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
For parallel
X
If parallel system
according to
number of units
X
X
X
X
X X
If present
If present
X
X
DELPHYS MP/ DELPHYS BC/
MX GP
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
For parallel For parallel
If parallel system If parallel system
according to according to
number of units number of units
X X
X X
X X
X X
X X
If present If present
X X
X X
