13. UPS MONITORING

13.1. UNIT SYNOPTIC

13.1.1. SYNOPTIC ANIMATION
15
11
19
1 2
ELEMENT
1
Rectifier input supply Not present
2
Rectifier
3
Rectifier output
4
DC Bus
5
Inverter input
6
Inverter
7
Inverter output
8
Output
9
Load
10
Battery
11
Bypass input supply
12
Bypass input
13
Bypass
14
Bypass output
15
Maintenance Bypass present
16
Bypass impossible
17
Maintenance alarm
18
Alarm present
19
Genset
20
Battery sharing
The output load rate value is reported to synoptic. The load value is not displayed if the mainte-
nance bypass is closed.
During battery charging and battery charged status, the battery capacity value in % is displayed.
The capacity value is replaced by the remaining backup time when the battery is discharging.
NET-VISION 7 - SOCOMEC
12
20 10
3 4 5
GREY
Present
Rectifier off Rectifier on
Rectifier off Rectifier on
Rectifier off Rectifier on
Inverter off Inverter on
On inverter or
off
On eco mode
0% Up to 90%
default
Not present Present
Not present Present
Bypass on
Bypass off
and eco mode
If one alarm present
Genset on
Present if the battery
is shared with all other
Units in parallel system
9
13 14
16
8
6 7
GREEN YELLOW
On + prev. alarm
On battery
On + prev. alarm
On battery
On bypass or
On battery
Above 90%
Battery room or temp,
alarm or test failed
Bypass on
On + prev. alarm
Bypass on
On maintenance bypass
Impossible
Active
17
18
RED
On + critical alarm
On + critical alarm
Above 100%
Battery alarm
On + critical alarm
Locked
