13.1.6. BATTERY PARAMETERS TABLE
"Battery Status
The status list displayed depends on the type of
UPS range. Depending on the range and UPS
functionalities, parts of the status list are not man-
aged.
"Battery voltage
"Battery capacity
"Battery capacity
"Remaining Backup time
"Battery temperature
"Time since on battery power
13.1.7. OUTPUT PARAMETERS TABLE
" "
Output Status
The status list displayed depends on the
type of UPS range. The status list is not
available for all UPS, depending on the
range and UPS functionalities
"Output load rate
"Output Power
"Output Power
"Output Current
"Output Voltage
"Output Frequency
24 GB
"Battery Parameters"
(V)"
(%)"
(Ah)"
(mn)"
(°C)"
(mn)"
"Output Parameters"
(%)"
(kVA)"
(kW)"
(A)"
(V)"
(Hz)"
"Unknown"
"Battery disconnected"
"Battery discharged"
"Battery low"
"Battery discharging"
"Battery to input" – specific function (optional)
"Battery alarm"
"Battery room alarm" – if sensor present
"Battery temperature alarm" – if sensor present
"Battery test running"
"Battery charging"
"Battery OK"
In case of 2 battery strings, the global voltage is dis-
played.
Value present in the table during the battery discharg-
ing when computed or indicates the nominal backup
time in normal operation
If the temperature sensor is present (option)
Present only during battery discharging
"
Unknown" – if no com with UPS
"On maintenance bypass"
"Load protected by inverter"
"Normal mode" – for OFF LINE UPS
"eco mode"
"Load on Bypass"
"On standby"
"Load OFF"
Per phase
Present if computed by UPS
Present if computed by UPS
Per phase
Per phase
