10. NET VISION 6 FUNCTIONS

Please refer to the dedicated NET VISION 6 User manual, for all related functions.
The following chapters concern NET VISION 7

11. RESET NET VISION WITH FACTORY SETTINGS

When removing NET VISION from the network, make sure it does not affect your remote
monitoring system.
1. Remove Network cable and EMD if present
2. Unscrew and remove the board
3. Set SW1 and SW2 according to requirements
4. Replace the board in the Com-Slot
5. Wait for NET VISION to restart: Green/Yellow EMD LED fixed ON
6. Remove the board again
7. Set SW1 and SW2 to OFF position – Normal mode
8. Replace the board in Com-Slot and tighten screw
9. Wait for NET VISION to restart for a new operation
DIP SWITCH functions
NORMAL MODE
ADMIN PASSWORD RESET
RESET TO FACTORY DEFAULT
If functions have been set before this procedure (email, SNMP, Shutdown ...) those
functions will need to be reconfigured.
The RESET button does not affect the Net Vision settings, it only restarts Net Vision.
Make sure that the IP given by the DHCP server remains the same as before the Net Vision RESET.
14 GB
SW1 SW2 SW3
OFF OFF
On OFF
OFF On
SW4
X X
X X
X X
