7.3. UPS DATA BASE

NET VISION manages 2 types of UPS mapping:
• 'JBUSP' mapping for NETYS PR - RT / ITYS / MODULYS / MASTERYS MC-BC-GP-IP-EM /
DELPHYS BC-GP-Xtend
• 'VU-MAP' mapping for ITYS-PRO / MODULYS GP 2.0 / MASTERYS BC+ and GP4 ranges and
future SOCOMEC UPS range.
JBUSP TABLES
VU-MAP TABLES
MODBUS TCP access must follow the addresses according to the UPS mapping
Please refer to the Appendix: MODBUS TCP JBUSP and VU-MAP TABLE.

7.4. UPS ARCHITECTURE:

• Single Unit 1 phase and 3 phases
• Converter - without battery
• Module – without bypass
• Modular Unit up to 8 modules
• Parallel system, distributed bypass or centralized bypass, up to 6 Units (JBUSP) and 10 Units
(VU-MAP)
• Modular system up to 3 Units – 24 modules.
10 GB
STATUS
ALARMS
MEASUREMENTS
STATUS
ALARMS
MEASUREMENTS
S00 – S63 0x1020
A00 – A63 0x1040
M00 – M47 0x1060
S000 – S127 0x0030
A000 – A127 0x0038
M000 – M079 0x0040
4 w
4 w
48 w
8 w
8 w
80 w
