13.2. SYSTEM SYNOPTIC

13.2.1. ANIMATION
ELEMENT
1 Rectifier input supply
7 Inverter output
8 Output
9 Load
11 Bypass input supply
12 Bypass input
14 Bypass output
15 Maintenance Bypass
13.2.2. NAVIGATION
Clicking on the System
below the synoptic.
Clicking on the
"
UPS Parameters Table"
13.2.3. UPS PARAMETERS TABLE
The table is updated with data read from the UPS at System level, which is a combination from
all Unit data.
See "
Unit/UPS Parameters Table"
13.2.4. UPS OUTPUT PARAMETERS TABLE
The table is updated with data read from the UPS at System level, which is a combination from
all Unit data.
See UPS "
Output Parameters Table"
26 GB
15
11
1
GREY
Not present
Inverter off
off
0%
Not present
Not present
Bypass off
Present
and output load symbols
button or "
Comprehensive View
.
12
14
8
7
GREEN YELLOW
Present
Inverter on On battery
On inverter On bypass
On eco mode On battery
Up to 90% Above 90%
Present
Present Bypass on
Bypass on and
Bypass on
eco mode
On maintenance
bypass
shows the related parameters table
" in the Monitor menu switches back to the
9
RED
Above 100%
