Hardware overview
This chapter includes the following topics:
■
■
■
■
■
■
■
NetBackup 5330 appliance overview
The front panel of the appliance contains 12 disk drive slots. The slots are numbered
from zero (lower left slot) to 11 (upper right slot).
Disk drives in the NetBackup 5330 appliance include the following:
■
NetBackup 5330 appliance overview
NetBackup 5330 appliance PCIe card configurations
NetBackup 5330 Appliance Ethernet port configurations
NetBackup 5330 storage shelves and disk drives
NetBackup 5330 cables and connectors
Understanding the NetBackup 5330 hardware installation sequence
About IPMI configuration
Eight 3TB SAS disks, which can be accessed from the NetBackup 5330
Appliance front panel. The disks are configured into two RAID 1 volumes, which
are labeled Volume 0 and Volume 1. The disks that are located in slot 0 and
slot 1 are configured as the RAID 1, Volume 0 device. This volume contains the
appliance operating system and the NetBackup application.
