Connecting the power cords to the NetBackup 5330 appliance and to the storage shelves
200 - 240 VAC at 50/60 Hz, 4.4 A
■
2
Verify that the AC power supply input for the storage shelves is within the range
of 200 - 240 VAC at 50/60 Hz, 9.13 - 10.95 A.
3
For each component, obtain two power cords that are appropriate for your
region and equipment.
4
On the appliance, connect a power cord to each power supply socket. Connect
the other end of each cord to a different PDU.
5
On the Primary Storage Shelf, connect a power cord to each power supply
socket. Connect the other end of each cord to a different PDU.
6
On the Expansion Storage Shelf, connect a power cord to each power supply
socket. Connect the other end of each cord to a different PDU.
Hardware installation procedures
47
