Understanding the NetBackup 5330 hardware installation sequence
Storage shelf and appliance hardware installation sequence
Table 1-3
Step Description
1 Determine the rack location for the storage shelves and the appliance.
See "Determining rack locations for NetBackup 5330 hardware"
2 Unpack the Expansion Storage Shelf and the Primary Storage Shelf.
See "Unpacking a Primary Storage Shelf or an Expansion Storage Shelf"
on page 21.
3 Mount the storage shelf rails in the rack and install the storage shelf.
Note:
The following topic can be used for both the Expansion Storage Shelf and
the Primary Storage Shelf.
See "Installing a Primary Storage Shelf or an Expansion Storage Shelf"
4 Unpack the NetBackup 5330 Appliance.
See "Unpacking a NetBackup 5330 appliance"
5 Mount the appliance rails in the rack and install the appliance.
See "Installing the NetBackup 5330 appliance"
6 Install the disk drives into each storage shelf.
See "Installing disk drives into a Primary Storage Shelf or an Expansion Storage
Shelf " on page 35.
7 For the primary storage shelf only: Connect the four fiber channel cables between
the primary storage shelf and the appliance.
See "Connecting the NetBackup 5330 appliance to the Primary Storage Shelf"
on page 43.
8 For the Expansion storage shelf only: Connect the four SAS cables between the
Expansion shelf and the primary shelf.
See "Connecting the Primary Storage Shelf to the Expansion Storage Shelf"
on page 45.
9 Connect the Power Distribution Unit (PDU) cords between the appliance and the
power distribution outlets in the rack
See "Connecting the power cords to the NetBackup 5330 appliance and to the
storage shelves" on page 46.
Hardware overview
on page 26.
on page 27.
on page 22.
on page 37.
