Throttle Level Enable/Disable
HF-y represents throttle level is enabled. HF-N represents throttle
level is disabled. The default value is N.
To change throttle level function, press the UP/DOWN button to
select Y or N.
To store a changed setting, press the MODE button and then
access Throttle Enable Settings page.
To return to previous menu, hold the MODE button for 2s.
◆System Settings
Delay time settings of battery power
DLY represents delay time of battery power settings. The default
value is 3s.
To change delay time settings, press the UP/DOWN button to select
delay time 3s, 6s, 12s.
To store a changed setting, press the MODE button and then access
the max speed limited.
Max speed limited
MAX SPD represents max speed limited settings. The default value is
40Km/h.
To change Max speed limited setting, press the UP/DOWN button to
set the max speed from 25Km/h to 40 Km/h.
To store a modified setting, press the MODE button and then access
Button PAS Settings.
Throttle Level Enable or Disable Interface
Delay Time of Battery Power Interface
13
