Ruckus Wireless
™
ZoneFlex
SmartCell
8800
™
™
(SC8800-S) Outdoor Access Point
Installation Guid e
Part Numb e r 800-70420-001 Re v B
Pub lishe d Ap ril 2013
www.ruckuswire le ss.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC8800-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruckus Wireless SC8800-S

Summary of Contents for Ruckus Wireless SC8800-S

  • Page 1 Ruckus Wireless ™ ZoneFlex SmartCell 8800 ™ ™ (SC8800-S) Outdoor Access Point Installation Guid e Part Numb e r 800-70420-001 Re v B Pub lishe d Ap ril 2013 www.ruckuswire le ss.com...

  • Page 3: Table Of Contents

    Planning the SC8800-S AP Installation ........
  • Page 4 Installing the SC8800-S AP in the Field ........
  • Page 5 Appendix A: Ruckus Wireless-Supplied and Customer-Ordered Parts ....61 Appendix B: Resetting the Access Point to Factory Default Settings ....65...

  • Page 7: About This Installation Guide

    This Installation Guide provides information on how to add the Ruckus Wireless Smart- Cell™ 8800 Access Point (SC8800-S AP , or AP) to your Ruckus Wireless network. Topics covered in this guide include installing, basic configuring, and device mounting. This guide is intended for use by those responsible for installing and setting up network equipment.
  • Page 8 • Pointing the Internal GPS Antenna • Performing a Site Survey • Planning the Physical Installation Preparing the SC8800-S AP at the Depot and Shipping to the Field • Unpacking the AP • Powering the AP • Configuring the AP for Management by ZoneDirector •...

  • Page 9: Related Documentation

    About this Installation Guide Related Documentation Related Documentation In addition to this guide, each Ruckus Wireless SC8800-S AP documentation set includes the following: User Guide : Provides detailed information on how to configure the AP . The ZoneFlex ■ Outdoor AP User Guide is available for download on the Ruckus Wireless Support Web site at https:/ / support.ruckuswireless.com/documents...

  • Page 10: Planning The Sc8800-S Ap Installation

    Planning the SC8800-S AP Installation About the AP Planning the SC8800-S AP Installation Before installing the SC8800-S AP , it is helpful to verify the version and to plan the AP installation: About the AP ■ Pointing the Internal GPS Antenna ■...
  • Page 11 Planning the SC8800-S AP Installation About the AP The AP is equipped with two 5GHz N-type connectors, which allow operators to use up to two customer-supplied external 5GHz antennas instead of the internal 5GHz antennas. These external antennas can support operator-defined coverage areas and point-to-point deployments.

  • Page 12: Ap Connectors And Leds

    Planning the SC8800-S AP Installation AP Connectors and LEDs AP Connectors and LEDs Figure 5 identifies the top-panel connectors on the AP . Table 2 describes these connectors. Figure 5. Top-panel connectors Table 2. Top-panel connectors Label Description 5 GHz 5GHz 50-ohm N-type connector.
  • Page 13 “ Appendix A: Ruckus Wireless-Supplied and Customer-Ordered Parts” page 61 to order a Ruckus Wireless 60W PoE injector.) FIBER port This waterproof gland allows you to run a fiber-optic cable into the SC8800-S chassis to an optional fiber modem. LEDs...
  • Page 14 Planning the SC8800-S AP Installation AP Connectors and LEDs Figure 7 identifies the AP bottom-panel LED locations on the AP . Table 4 describes these connectors and LEDs. Figure 7. LEDs Table 4. LED descriptions Label Description PWR LED • Off: No power is available, or the AP is not connected to a power source.
  • Page 15 Planning the SC8800-S AP Installation AP Connectors and LEDs Table 4. LED descriptions (Continued) Label Description AIR LED • Off: The AP is in standalone mode, or acting as a Root AP if in mesh mode. • Solid Green: The AP is functioning as a Mesh AP (MAP) and the uplink signal quality is good (>24dBm).

  • Page 16: Pointing The Internal Gps Antenna

    Planning the SC8800-S AP Installation Pointing the Internal GPS Antenna Pointing the Internal GPS Antenna The AP includes an internal GPS antenna. When the AP is to be used with the optional GPS feature enabled, the GPS antenna must be mounted outdoors and have as clear a view of the sky as possible (as close as possible to 360 degrees, and with no obstructing trees or buildings).

  • Page 17: Performing A Site Survey

    Performing a Site Survey Perform a site survey to determine the optimal AP placement or maximum range, coverage, and network performance. Ruckus Wireless Support can supply Site Survey best practices information. The location and orientation that you choose for the AP play a critical role in the performance of your wireless network.

  • Page 18: Planning The Physical Installation

    The AP only requires one power source (either AC or PoE), but can be powered by AC ■ and PoE at the same time. The AP may be powered by AC power or by PoE input using an Ruckus Wireless 60W ■ PoE injector (part number 902-0180-XX00, where XX is the country code).

  • Page 19: Preparing The Sc8800-S Ap At The Depot And Shipping To The Field

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Unpacking the AP Preparing the SC8800-S AP at the Depot and Shipping to the Field Unpacking the AP ■ AP Connectors and LEDs ■ Powering the AP ■...

  • Page 20: Mounting Kit Contents

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Powering the AP M ounting Kit Contents NOTE: “ Appendix A: Ruckus Wireless-Supplied and Customer-Ordered Parts” page 61 includes pictures and descriptions of these and other factory-orderable and customer-supplied parts.

  • Page 21: Configuring The Ap For Management By Zonedirector

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by ZoneDirector Configuring the AP for M anagement by ZoneDirector 1. Collect required equipment and information: • One Cat5e or better Ethernet cable.
  • Page 22 Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by ZoneDirector NOTE: If the ZoneDirector is set to Enable Mesh , it automatically assigns the AP as a Root AP . Continue with “...

  • Page 23: Configuring The Ap For Management By Flexmaster Or For Standalone Operation

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by FlexMaster or for Standalone Operation Configuring the AP for M anagement by FlexM aster or for Standalone Operation 1. Collect required equipment and information: •...
  • Page 24 Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by FlexMaster or for Standalone Operation 4. Write down all of the currently active network settings. You will need this information later when you restore your computer to its current network configuration.

  • Page 25: Connecting The Ap To The Administrative Computer

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by FlexMaster or for Standalone Operation Connecting the AP to the Administrative Computer 1. Verify that the AP is powered on as described in “...

  • Page 26: Configuring Common Wireless Settings

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by FlexMaster or for Standalone Operation Configuring Common Wireless Settings The settings on the Common tab are required to enable wireless devices to associate with the AP .
  • Page 27 Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by FlexMaster or for Standalone Operation Table 7. Common wireless configuration Setting Recommended Value Wireless Mode • 2.4GHz (802.11b/ g/ n) for Configuration > Radio 2.4G > Common.

  • Page 28: Configuring Wireless # Settings

    4. Clear the SSID box, and then type a unique and descriptive name that you want to call this wireless network. For example, you can type Ruckus Wireless AP . This SSID is the name that helps users identify this wireless network in their wireless network connection application.

  • Page 29: (Optional) Setting The Flexmaster Server Address

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by FlexMaster or for Standalone Operation If you are configuring the AP for management by FlexMaster, then continue with “ (Optional) Setting the FlexMaster Server Address”...
  • Page 30 Preparing the SC8800-S AP at the Depot and Shipping to the Field Configuring the AP for Management by FlexMaster or for Standalone Operation 4. In FlexMaster Server URL, type the URL of the FlexMaster server on the network. You can use either http or https to connect to the URL and include either the host name or IP address of the FlexMaster server in the URL.

  • Page 31: Verifying Ap Operation

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Verifying AP Operation Verifying AP Operation Ruckus Wireless recommends that you verify that the AP is operating correctly. NOTE: You can perform these verification tasks indoors. To verify that the AP is operating correctly, perform the following procedures: Connecting the AP to the Network ■...

  • Page 32: Associating A Wireless Client With The Ap

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Verifying AP Operation 5. Continue with “ Associating a Wireless Client with the AP” page 6. Connect the Ethernet cable from the Data In port on the PoE injector to your network’s router or switch.

  • Page 33: Disconnecting The Ap From The Power Source And The Network

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Verifying AP Operation Disconnecting the AP from the Power Source and the Network 1. Disconnect the AP from the power source (either from the PoE injector or AC power source).

  • Page 34: Shipping The Ap To The Field

    Preparing the SC8800-S AP at the Depot and Shipping to the Field Shipping the AP to the Field 3. When the Local Area Connection Properties dialog box appears, select Internet Protocol (TCP/ IP) from the scrolling list, and then click Properties . The TCP/ IP Properties dialog box appears.

  • Page 35: Installing The Sc8800-S Ap In The Field

    AC installation. Note which components must be installed indoors and outdoors. Ruckus Wireless strongly recommends 80mm - 130mm (3” -5” ) drip loops on any cables ■ that are installed outdoors (for example, on an outdoor AP).
  • Page 36 Installing the SC8800-S AP in the Field Installation Components and Constraints WARNING: Installation of this equipment must comply with local and national electrical codes. Make sure that you form a 80mm - 130mm (3” -5” ) drip loop in any cable that CAUTION: is attached to the AP or the building.
  • Page 37 Installing the SC8800-S AP in the Field Installation Components and Constraints Figure 16. Typical outdoor AC installation components Indoor Outdoor ZoneFlex SC8800-S Ground Outdoor AP screw Drip loops Router Cat5 Ethernet or switch cable Surge Drip AC power Ground protector...

  • Page 38: Deploying The Access Point

    Installing the SC8800-S AP in the Field Deploying the Access Point Deploying the Access Point In this section, you will mount the AP in its final mounting location and verify its operation. Perform the following: Connecting and Sealing the RJ-45 Cables ■...

  • Page 39: Connecting And Sealing The Rj-45 Cables

    Cable gland base Clamping ring assembly Rubber O-ring Sealing nut 3. Remove the required ( RESET/ PoE OUT or PoE IN ) blanking cap from the SC8800-S. (See Figure 6 for cap location.) 4. Connect the cable to the ethernet port in the SC8800-S.

  • Page 40: Preparing The Power Connections

    Installing the SC8800-S AP in the Field Deploying the Access Point Preparing the Power Connections The AP supports both AC power and PoE and it can be connected to both power sources at the same time. If you want use both power sources, complete these power connections using both of these two methods: •...
  • Page 41 Installing the SC8800-S AP in the Field Deploying the Access Point Figure 18. Assembling the AC power connector Wire Stripping Drawn Actual Size (1:1) Earth Ground Neutral/Return Line/Hot (not used) 4. Feed the end of the AC cable through the boot and cable gland.
  • Page 42 Access Point Operation” page You have prepared the AC power connection. Preparing the PoE Power Connection 1. Obtain a Ruckus Wireless 60W PoE injector. (Refer to “ Appendix A: Ruckus Wireless- Supplied and Customer-Ordered Parts” page 61 to order a Ruckus Wireless 60W PoE injector.)

  • Page 43: Mounting The Access Point

    Installing the SC8800-S AP in the Field Mounting the Access Point M ounting the Access Point The AP package includes a mounting bracket kit shown in Figure 19. The kit components are described in Table Figure 19. AP Mounting Bracket Exploded Assembly...
  • Page 44 Installing the SC8800-S AP in the Field Mounting the Access Point Table 9. AP Mounting Bracket Kit Description No. Interface Element Description Main Mounting Mounting bracket for use on flat surfaces and poles. Bracket Designed for use with the following fasteners: •...

  • Page 45: Mounting The U-Joint Bracket To The Main Mounting Bracket

    The main mounting bracket can be attached to a flat surface using small or large bolts or screws as described in Table WARNING: Ruckus Wireless strongly recommends that you wear eye protection before drilling holes in the mounting surface. 1. Place the main mounting bracket at the location on the mounting surface where you want to mount the AP .

  • Page 46: Attaching The Main Mounting Bracket To A Wooden Pole

    The main mounting bracket can be attached to a wooden pole using carriage bolts as described in Table WARNING: Ruckus Wireless strongly recommends that you wear eye protection before drilling holes in the pole. 1. Place the main mounting bracket at the location on the mounting surface where you want to mount the AP .
  • Page 47 Installing the SC8800-S AP in the Field Mounting the Access Point Figure 22. Wooden Pole Mounting Hole Locations Table 12. Main Mounting Bracket Carriage Bolt Holes No. Interface Element Description Square Holes Designed for use with two customer-supplied M16 (5/ 8” ) (2 places) carriage bolts.

  • Page 48: Attaching The Main Mounting Bracket To A Metal Pole

    Installing the SC8800-S AP in the Field Mounting the Access Point Attaching the M ain M ounting Bracket to a M etal Pole The main mounting bracket can be attached to a metal pole using stainless steel adjustable clamps as described in Table 1.

  • Page 49: Mounting The Hook Bracket To The U-Joint Bracket

    Installing the SC8800-S AP in the Field Mounting the Access Point 4. Continue with “ Mounting the Hook Bracket to the U-Joint Bracket” page M ounting the Hook Bracket to the U-Joint Bracket The hook bracket attaches to the U-joint bracket using the large M8 bolt and washer set.

  • Page 50: Assembling The Ap Attachment Bracket And The Access Point

    Installing the SC8800-S AP in the Field Mounting the Access Point Assembling the AP Attachment Bracket and the Access Point 1. Place the AP attachment bracket onto the back side of the AP so that the four screw holes on the bracket align with the four screw holes on the AP . Make sure that the longer end of the AP attachment bracket is on the same side as the AP antenna connectors.

  • Page 51: Attaching The Ap Attachment Bracket And Ap To The Hook Bracket

    Installing the SC8800-S AP in the Field Mounting the Access Point Attaching the AP Attachment Bracket and AP to the Hook Bracket 1. Slide the AP attachment bracket and AP assembly onto the hook bracket. MAKE SURE that the AP attachment bracket slides securely onto the hook CAUTION: bracket.

  • Page 52: Safety-Cabling The Ap

    Installing the SC8800-S AP in the Field Mounting the Access Point Safety-Cabling the AP 1. Collect the 1/ 8” (3mm) diameter galvanized steel safety cable with loop on one end and retaining washer on the eye end (24” , 610 mm).
  • Page 53 Installing the SC8800-S AP in the Field Mounting the Access Point 3. Use one small M6 bolt and washer set to attach the eye end of the safety cable to a threaded boss on the back of the AP . Tighten the bolt to 9.5 N.m (7 ft-lbs).

  • Page 54: Mounting External Antennas (Optional)

    Installing the SC8800-S AP in the Field Mounting the Access Point M ounting External Antennas (Optional) NOTE: Mount internal and external antennas at least 20cm (7.9” ) away from each other. You can connect one or two 5GHz external antennas to the 5 GHz ANT 0 and 5 GHz ANT 2 50-ohm N-type female connectors on the AP .
  • Page 55 Installing the SC8800-S AP in the Field Mounting the Access Point 7. Use a torque wrench to tighten the connectors to 1.58 N.m (14 in-lbs). If you do not have a torque wrench, then hand-tighten the connectors until the internal washers are compressed, but do not overtighten.

  • Page 56: Verifying Access Point Operation

    Installing the SC8800-S AP in the Field Verifying Access Point Operation Verifying Access Point Operation After mounting the AP , Ruckus Wireless strongly recommends that you verify that the AP is operating correctly. To do this, you will need to do the following: Powering the AP ■...
  • Page 57 Installing the SC8800-S AP in the Field Verifying Access Point Operation Powering the AP with AC 1. Collect required tools and supplies: • An outdoor-rated three-wire (1-2mm or 14-18AWG) AC cable long enough to connect the AP with the AC power source.
  • Page 58 NOTE: If the PWR LED does not turn on at all, one or both of the AC power supply fuses inside the SC8800-S chassis may have burned out. Open the SC8800-S cover and replace any burned-out 5A, 250V, slow-blow fuse(s), as required.

  • Page 59: Connecting The Ap To The Network

    Installing the SC8800-S AP in the Field Verifying Access Point Operation Connecting the AP to the Network The AP can connect to the network using data cables, or can connect to the network using wireless backhaul if it is part of a mesh network.

  • Page 60: Configuring The External Antenna Gain

    Installing the SC8800-S AP in the Field Verifying Access Point Operation Configuring the External Antenna Gain You can configure the maximum gain for each set of 5GHz and 2.4GHz external antennas connected to the AP (“ Mounting External Antennas (Optional)”...
  • Page 61 Installing the SC8800-S AP in the Field Verifying Access Point Operation Figure 30. Configure the external 5GHz antenna gain - AP web interface 3. In External Antenna , click Enabled . 4. In External Antenna Gain , enter the antenna gain value (in dBi).
  • Page 62 Installing the SC8800-S AP in the Field Verifying Access Point Operation 3. In the Model Specific Control parameter, select ZoneFlex AP . ZoneDirector displays the External Antenna entries. Figure 31. Configure the 5GHz antenna gain - ZoneDirector 4. In the External Antenna section: •...
  • Page 63 Installing the SC8800-S AP in the Field Verifying Access Point Operation Configuring 2.4GHz External Antenna Gain The AP allows you to configure the gain of up to two customer-supplied 2.4GHz external antennas. The maximum value for the antenna gain that you should set depends on the type of external antennas that you are connecting to the AP .
  • Page 64 Installing the SC8800-S AP in the Field Verifying Access Point Operation 5. If you made any changes to the Common tab, click Update Settings . You have configured the 2.4GHz antenna gain. Continue with “ Associating a Wireless Client with the AP”...

  • Page 65: Associating A Wireless Client With The Ap

    Installing the SC8800-S AP in the Field Verifying Access Point Operation Associating a Wireless Client with the AP 1. In the client device's wireless interface, select the SSID configured in the “ Configuring Wireless # Settings” page 22 section. 2. Connect the client device to the selected WLAN SSID.

  • Page 66: What To Do Next

    Configuring Advanced Settings and Features The AP has been configured for basic operation. However, the Ruckus Wireless AP supports many advanced settings and features. Refer to the ZoneFlex Outdoor Access Point User Guide , ZoneDirector User Guide , or FlexMaster User Guide for instructions on how to configure the advanced setting and feature parameters.
  • Page 67 Appendix A: Ruckus Wireless-Supplied and Customer-Ordered Parts Table 20. Ruckus Wireless- and customer-supplied parts Part Ruckus Factory Kit Notes Wireless P/ N Customer Ordered Main Mounting Bracket Factory AP (1 piece) Mounting U-Joint Bracket Factory AP (1 piece) Mounting Small M6 Bolt and Washer Sets-...
  • Page 68 Table 20. Ruckus Wireless- and customer-supplied parts (Continued) Part Ruckus Factory Kit Notes Wireless P/ N Customer Ordered 1/ 2” (12.7mm) wide stainless Factory AP Stainless steel adjustable clamps, 2.5- Mounting steel inch (63.5mm) diameter (4 pieces) M 25 waterproof ethernet cable...
  • Page 69 Table 21. Orderable 2.4GHz Antennas (Continued) Part Ruckus Notes Wireless P/ N 2.4GHz 6dBi H External Omni Outdoor 911-0006- Kit includes Antenna HP01 horizontally -polarized antenna Table 22. Orderable 5GHz Antennas Part Ruckus Notes Wireless P/ N 5GHz 12dBi 911-1212- 120-degree 2x2 Dual-Polarized Sector DP01 Outdoor Antenna...
  • Page 70 Table 22. Orderable 5GHz Antennas (Continued) Part Ruckus Notes Wireless P/ N 5GHz 5dBi H External Omni Outdoor 911-0536- Kit includes Antenna HP01 horizontally- polarized antenna 5GHz 5dBi H and V External Omni 911-0636- Kit includes Outdoor Antennas VH01 vertically- and one horizontally- polarized...

  • Page 71: Factory Default Settings

    Appendix B: Resetting the Access Point to Factory Default Settings You can reset the AP to its factory default settings by pressing the reset button located inside the PoE OUT/ RESET port. 1. Remove the PoE OUT/ RESET blanking cap or cable gland. 2.
  • Page 72 Appendix C: Installer M ounting Dimensions All dimensions are in millimeters. Figure 34. SC8800-S dimensions...
  • Page 74 Ruckus Wireless, Inc.
  • Page 76 Copyright © 2006-2013. Ruckus Wireless, Inc. 350 West Java Dr. Sunnyvale, CA 94089. USA www.ruckuswireless.com...
