SuperTrak Installation Task List
• Task 1: Unpacking Your SuperTrak, below
• Task 2: Installing the SuperTrak Card (page 5)
• Task 3: Choosing the Physical Drives (page 7)
• Task 4: Creating a Logical Drive (page 8)
• Task 5: Installing Software Drivers (page 12)
• Task 6: Installing WebPAM PRO (page 13)
• Task 7: Logging into WebPAM PRO (page 15)
• Task 8: Setting up WebPAM PRO (page 16)
Task 1: Unpacking Your SuperTrak
When you receive the SuperTrak EX SAS/SATA RAID Controller card, the
package should contain the items listed below:
• SuperTrak EX16650 Controller card
• Four 0.5m (19-inch) SFF-8087 to SFF-8087 multi-lane cables
Quick Start Guide
•
• CD with WebPAM PRO software, Windows and Linux drivers, and
SuperTrak User Manual
If any of the items are missing or appear damaged, please contact your dealer or
distributor immediately.
The electronic components on the SuperTrak EX Controller cards
are sensitive to damage from Electro-Static Discharge (ESD).
Observe appropriate precautions at all times when handling the
SuperTrak card or its subassemblies.
Before installing the SuperTrak EX Controller card into an existing
system, backup any important or useful data. Failure to follow this
accepted practice could result in data loss.
Task 1: Unpacking Your SuperTrak
Warning
Warning
