Vehicle Installation - Wilson Electronics SIGNALBOOST MobilePro Installation Manual

Before Getting Started
This guide will help you properly install Wilson's SIGNALBOOST
Wireless Cellular/PCS Amplifi er. It is important to read through all of the installation
steps for your particular application prior to installing any equipment. Read through
the instructions, visualize where all the equipment will need to be installed and do a soft
installation before mounting any equipment. If you do not understand the instructions in full,
seek professional help, or contact Wilson Technical Support at 866-294-1660.
Installation Diagram - Vehicle
MobilePro
™
Amplifier

Vehicle Installation

3
Ou Outside
An Antenna
(m (mounted
on on vehicle)
Cigarette lighter
power supply
USB Power Cable
Exterior antenna
1
communicates with
cell site.
See detailed instructions on page 5
™ MobilePro ™
Laptop USB Port
Amplifier boosts
2 2
signal to and from
cell site.
3
POWER TO
AMPLIFIER
Amplifier powered through
vehicle cigarette lighter or
USB port of laptop computer.
Dual-Band
