Amplifier
Amplifier
Installation
stallatio
stallat
Guide
Contents:
Guarantee and Warranty · · · · · · · · · · · · · · · · · · · · · · · ·
How it Works · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
Before Getting Started · · · · · · · · · · · · · · · · · · · · · · · · · · 3
Installing a Wilson Outside Antenna · · · · · · · · · · · · · · ·
Installing the Low-Profi le Antenna · · · · · · · · · · · · · · · · · 6
Powering Up a Wilson Amplifi er · · · · · · · · · · · · · · · · · · · 7
Warnings and Recommendations · · · · · · · · · · · · · · · · · 8
Understanding the Amplifi er Lights · · · · · · · · · · · · · · · · 9
About Wilson Electronics · · · · · · · · · · · · · · · · · · · · · · · 10
Amplifi er Specifi cations · · · · · · · · · · · · · · · · · · Back Cover
Mobile Wireless
Dual-Band
Cellular / PCS
Amplifi er
!
Warning: This manual contains
important safety and operating information.
Please read and follow the instructions
in this manual. Failure to do so could be
hazardous and result in damage to your
amplifi er.
1
4
Wilson
®
Electronics, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wilson Electronics 271245
Summary of Contents for Wilson Electronics 271245
-
Page 1: Table Of Contents
Understanding the Amplifi er Lights · · · · · · · · · · · · · · · · 9 About Wilson Electronics · · · · · · · · · · · · · · · · · · · · · · · 10 Amplifi... - Page 2 Returned Material Authorization (RMA) number supplied by Wilson Electronics. Wilson shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer.
-
Page 3: How It Works
Wilson Electronics manufactures a wide variety of antennas to help you customize your amplifi er for your specifi c application. Several are shown below. See your dealer or visit www.wilsonelectronics.com. -
Page 4: Before Getting Started
Before Getting Started This guide will help you properly install Wilson’s dual-band, mobile wireless amplifi er. It is important to read through all of the installation steps for your particular application prior to installing any equipment. Read through the instructions, visualize where all the equipment will need to be installed and do a soft installation before mounting any equipment. - Page 5 Installing a Wilson Outside Antenna To receive the best cell signal, select a location in the center of the vehicle’s roof 12 inches away from any other antennas and free of obstructions. Follow the specifi c antenna installation instructions included with the outside antenna (sold separately).
-
Page 6: Installing A Wilson Outside Antenna
Installing a Wilson Amplifi er Warning: Do not plug in the DC power supply until the outside and inside antenna cables are attached to the amplifi er. Select a location to install the amplifi er that is away from excessive heat, direct sunlight or moisture and that has proper ventilation. -
Page 7: Installing The Low-Profi Le Antenna
Installing the Low-Profi le Antenna Amplifi er Install the low-profi le inside antenna 8-12 inches from where the cell phone or cellular Low-profi le data card will be used. Antenna Warning: Do not install the low-profi le antenna within four inches of metal. (Metal found inside the vehicle’s seat will not affect the antenna’s performance.) Place the inside antenna on the side of the... -
Page 8: Powering Up A Wilson Amplifi Er
Powering up a Wilson Amplifi er Carefully insert the power cable. IMPORTANT: Do not power up the ampli- fi er unless antenna cables are attached to amplifi er. NOTE: The aluminum casing of a Wilson amplifi er will adjust very quickly to the ambient temperature of its environment. -
Page 9: Warnings And Recommendations
Warnings and Recommendations Warning: In a wireless installation, do not plug the amplifi er directly into the cell phone or cellular data card using an antenna adapter. It will damage the cell phone or cellular data card. Warning: Do not plug in the DC power supply until the outside and inside antenna cables are attached to the amplifi... -
Page 10: Understanding The Amplifi Er Lights
Understanding the Amplifi er Lights The power light PWR will turn green when the amplifi er is successfully powered up. When the 800 MHz or 1900 MHz lights are lit green, the amplifi er is amplifying the outside signal. If one or both frequency lights turn red, oscillation is occurring and the amplifi... -
Page 11: About Wilson Electronics
About Wilson Electronics Wilson Electronics, Inc. has been a leader in the wireless communications industry for nearly 40 years. The company designs and manufactures amplifi ers, antennas and related components that signifi cantly improve cellular telephone signal reception and transmission in a wide variety of applications, both mobile and in-building. -
Page 12: Amplifi Er Specifi Cations
-21.1 dBm 6 V, .5 A - 1.5 A (subject to uplink power) Wilson Electronics, Inc. ® www.wilsonelectronics.com Dual Band 271245 / 801201 FME-Male 50 ohms 1.44 lbs or 0.65 kg 50 dB 60 dB 53.5 MHz / 47.7 MHz...
