Cut. When the optional media cutter is installed, it
automatically cuts media after each label is printed or can cut
after a specified number of labels have been printed using a
software cut command. It cuts continuous roll paper, labels, or
tag stock.
NOTE: This feature is currently not supported using the RFID
encoder.
•
Continuous. Printer prints on the media and sends it out the
front.
The default is Tear-Off Strip.

Paper Feed Shift

Represents the distance to advance a label (+ shift) or pull back
(– shift) when the Tear-Off Strip, Tear-Off, Peel-Off, or Cut Media
Handling option is enabled. The allowable range is -0.50 inches to
the current Label Length value setting up to a maximum of 12.80
inches in 0.01 inch increments.
The default is 0.00 inches.

Label Length

In most applications, the user-selected Label Length will match the
physical label length. Physical label length is the actual label length
of the media installed. Following is a list of different media types:
•
Die-cut labels: measurable length of the removable label
(leading edge to trailing edge). This does not include the
liner material or gap.
•
Tag stock with notches or holes: measurable length from
the trailing edge of one notch or hole to the trailing edge of
the next notch or hole.
•
Tag stock with black marks on the underside: measurable
length from the leading edge of one black mark to the
leading edge of the next black mark.
•
Continuous media (no label length indicators): measurable
length should be within + 1-2% of the Label Length value
entered.
