Positioning The Media Sensors

Lower
Media Sensor
Your printer is equipped with upper and lower media sensors that
detect the top-of-form position on media with label length indicators
(gaps, notches, holes, or black marks). The media sensors also
detect Paper Out conditions.
Use the handles on the lower media sensor to horizontally position
it in the center of the installed media. Slide the upper media sensor,
located in the slot under the printhead cover (see figure on
page 34), directly over the lower sensor.
Positioning The Media Sensors
Lower
Media Sensor
Handle (2)
35
