9.0 P -E C & C
ULSE CHO OATING OATING
9.1 Introduction to Pulse-Echo Coating Measurement (PECT)
In the previous sections we've discussed the need for detecting pits and flaws (pulse-echo)
in materials, along with the requirement to measure through and eliminate errors caused by
coated materials (echo-echo). Until now, both modes were needed in order accomplish both
tasks. Pulse-echo mode was used for flaw detection, and echo-echo mode was used to elim-
inate the coating thickness and provide a nominal material thickness only. With this in
mind, it often became cumbersome toggling between both modes respectively.
In a majority of applications involving coated materials, inspectors are often interested in
monitoring both the thickness of the material, as well as the thickness of the coating.
Therefore, the TI-CMX has been designed to provide the user with the ability to measure
the material and coating thicknesses simultaneously, while maintaining the ability to detect
flaws and pits all in a single mode called Pulse-Echo Coating (PECT). This is accom-
plished by using a custom hybrid combination mode utilizing properties from the basic
modes along with a group of special techniques and theoretical wave phenomena's.
The TI-CMX is preset to a coating velocity of 0.0850 in/µsec (2159 m/sec) from the facto-
ry. This velocity is a very close approximation of the common coating velocities found in
the field. However, the TI-CMX also has a built-in one and two point calibration options to
calibrate to coating samples with a known thicknesses.
There are two coating modes built into the TI-CMX:
1. Pulse-Echo Coating (PECT) – used during inspections where both the material
and coating thicknesses are required.
2. Coating Only (CT) – used during inspections where only the coating thickness is
required.
9.2 Enabling Pulse-Echo Coating Mode (PECT) & Coating (CT)
When the TI-CMX is initially powered up, the gauge will automatically check to see if the
transducer plugged into the gauge can be recognized. All Dakota Ultrasonics coating
enabled transducers are equipped with the auto recognition feature. If the TI-CMX doesn't
recognize that a special coating enabled transducer is plugged into the gauge, the coating
feature will be disabled entirely. There are a number of coating enabled transducers avail-
able from Dakota. Please contact us with your application requirements for additional
information on frequencies and diameters currently offered.
The coating modes can be enabled in three different ways:
1. On Power up and probe recognition.
2. By pressing MULTI MODE keypad.
3. From the tabbed menus under TUNE, MEASURE MODE.
The steps that follow will demonstrate all three methods in the order listed above.
T
ECHNIQUES
-38-
Normal temperature range
Most standard transducers will operate from 0∞F to 180∞F.
High temperature measurements
Special transducers and couplants are available for temperatures above 180∞F up to 650
with intermittent contact. It is necessary to cool the transducer, by submerging the trans-
ducer in water between readings, when measuring high temperatures.
Modes and temperature errors
In addition to errors caused by velocity changing with temperature, some modes (measu
ment techniques) are affected more than others. For example, dual element mode has lar
errors due to changes in temperature of the delay line. However, in multi-echo technique
auto temperature helps to minimize these errors.
4.6 Measurement Modes
In this section we will discuss the different measurements modes the TI-CMX is capable
operating in, the transducers required, and the reasons for using specific modes:
Pulse-Echo Mode (Flaw & Pit detection) – Coating Off (P-E)
Pulse-echo mode measures from the initial pulse (sometimes referred to as an artificial
zero) to the first echo (reflection). In this mode, either an automatic or manual zero can
performed depending on the zero probe function setting. If the manual mode has been
selected, the transducer is placed on a reference disk, located on top of the TI-CMX, and
key is pressed to establish a zero point for the particular transducer. If the Auto Zero fea
ture is enabled, a simple key press will perform an electronic zero to establish the same
zero point.
In this mode errors result from surface coatings and temperature variations.
Since pulse-echo only requires one reflection, it is the most sensitive mode for measurin
weak reflections (flaws) typically found when measuring heavily corroded metals.
V-Path Correction
Dual element delay line transducers have two piezoelectric elements
mounted at an angle on one end of the delay line. One element is used
for transmitting sound, while the other element only receives sound.
The two elements and their delay lines are packaged in a single housing
but acoustically isolated from each other with a sound barrier. This
allows the transducer the ability to achieve very high sensitivity for
detecting small defects. Also, the surface of the test material does not
have to be as flat in order to obtain good measurements.
Dual element transducers are normally used in pulse-echo mode for
finding defects, and in echo-echo mode for through coating measurements.
Dual element delay line transducers are usable over a range of 0.025 inches to 20 inches
depending on the material, frequency, and diameter.
A limitation of dual element delay-line transducers is the V shaped sound path. Because
sound travels from one element to another, the time versus thickness relationship is non-
linear. Therefore, a correction table in the instruments software is used to compensate fo
this error.
-19-
Dual Element
Transducer
showing
V-path of sign
