For Output
EX123/124/126
Enclosure IP65 (EX123, EX124), IP67 (EX126)
Maximum 16 outputs
EX123
Series
VQ2000/4000/5000
Common power supply of unit and valve
3
Enclosure IP65
Compatible with the VQ valves
U
Mount a unit to the U side of the manifold
D
Mount a unit to the D side of the manifold
Separate power supply of unit and valve
4
Enclosure IP65
Compatible with the VQ valves
U
Mount a unit to the U side of the manifold
D
Mount a unit to the D side of the manifold
Separate power supply of unit and valve
6
Enclosure IP67
Compatible with the SY/SV/VQC valves
D
Mount a unit to the D side of the manifold
Series
EX124
Series
VQ2000/4000/5000
How to Order SI Unit
EX12 3 U
Unit specifications
Mounting specifications
EX12 4 U
Unit specifications
Mounting specifications
EX12 6 D
Unit specifications
Mounting specifications
EX126
Series
SY3000/5000/7000
SV1000/2000/3000
S SL1
Communication protocol
SL1
Panasonic Industrial Devices SUNX Co., Ltd.: S-LINK (16 outputs)
SL2
Panasonic Industrial Devices SUNX Co., Ltd.: S-LINK (8 outputs)
UW1
NKE Corp.: Fieldbus System
UH1
NKE Corp.: Fieldbus H System
S DN1
Communication protocol
DN1
DeviceNet
DN1-X26
DeviceNet
MJ1
CC-Link
CS1
OMRON Corp.: CompoBus/S (16 outputs)
CS2
OMRON Corp.: CompoBus/S (8 outputs)
Note) DN1's occupied points are 16 inputs and 16 outputs,
while DN1-X26 has 0 inputs and 16 outputs.
S MJ1
Communication protocol
MJ1
CC-Link
VQC1000/2000/4000/5000
CE-compliant
—
—
—
—
CE-compliant
Note)
Note)
CE-compliant

EX12 EX12
EX140
EX180
EX260
EX250
EX600
EX500
EX510
PCA
EX





