EX180
Series
SI Unit Dimensions/Parts Description
EX180-SMJ3, SMJ5
EX180-SDN3, SDN4, SDN5, SDN6
788
77
80
93.3
77
80
93.3
Communication
connector
M3
Ground terminal
Before mounting connector (accessory)
Communication
connector
M3
Ground terminal
Before mounting connector (accessory)
Power supply connector
(Control unit power supply
for SI unit)
Power supply connector
(For solenoid valve)
Power supply connector
(For solenoid valve)
