LED Studio 3800T
LED Studio 3800D
PR-3800T
PR-3800D
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
Advertisement
Table of Contents
Related Manuals for PR Lighting LED Studio 3800T
Summary of Contents for PR Lighting LED Studio 3800T
- Page 1 LED Studio 3800T LED Studio 3800D PR-3800T PR-3800D This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
- Page 2 INDEX SAFE USAGE OF THE PROJECTOR……………………………………………………………………………… INSTALLING THE PROJECTOR………………………………………………………………………………….. CONTROL CONNECTION………………………………………………………………………………………… DMX TERMINATOR……………………………………………………………………………………………….. SETUP OPTIONS-PROJECTOR CONFIGURATION……………………………………………………………… TO SET THE DMX START ADDRESS…………………………………………………………………………….. OPERATION MENU……………………………………………………………………………………………….. DMX PROTOCOL…………………………………………………………………………………………………. INDICATION OF LED DIGITAL TUBE……………………………………………………………………………. MAINTENANCE…………………………………………………………………………………………………… TROUBLESHOOTING……………………………………………………………………………………………… TECHNICAL DATA………………………………………………………………………………………………… ELECTRICAL DIAGRAM………………………………………………………………………………………….. COMPONENT ORDER CODES…………………………………………………………………………………… BACK COVER…………………………………………………………………………………………………...
-
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton, check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector can be used only indoors, IP20. - Page 4 INSTALL THE PROJECTOR The projector is hung when used, but not hung by any of its side. It can be manually rotated within a range of 90 degrees. Before installation,Take 1 clamps and 1 safety cord out from the package and mount 1 clamp on the mounting handle of fixture with 1 retainer. Hang the fixture on the structure and fasten the screws attached to the clamp.
-
Page 5: Control Connection
CONTROL CONNECTION Connection between the controller and a projector and between one projector and another must be made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Please use the projector’s cannon 5- pin signal input and output cables as connection. The 5-pin signal connections are connected as shown in the figure above. -
Page 6: Dmx Terminator
DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. -
Page 7: To Set The Dmx Start Address
TO SET THE DMX START ADDRESS Each projector must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller. -
Page 8: Dmx Protocol
DMX PROTOCOL DMX Channel Mode CHANNEL FUNCTION DESCRIPTION Dimmer 000-255 000 - 007 Strobe 008 - 255 Strobe from slow to fast INDICATION OF LED DIGITAL TUBE DMX Signal DMX Indication NO DMX Signal 8/14... -
Page 9: Maintenance
MAINTENANCE f the projector is idle for a long time, To prolong the life of the projector, it is very important to do the maintenance work. I damp, So it should be cleaned to smoke or particularly dirty surroundings can cause greater accumulation of dirt on its cover and housing. maintain an optimum light output and at the same time to prevent it from being corrupted by acid gas. -
Page 10: Technical Data
TECHNICAL DATA VOLTAGES: AC 100V-240V 50/60Hz POWER CONSUMPTION: 70W@220V LED: Power consumption Quantity 1pcs Manufacturers Rated LED Life 50000 Hours COLOUR TEMPERATURE: PR-3800T：3200K PR-3800D：5600K DIMMER: 0-100% linearly adjustable COLOUR RENDERING INDEX Ra≥86 LUMINOUS FLUX PR-3800T：690lm PR-3800D：850lm BEAM ANGLE: Field angle(one-tenth-peak) θ : 29°... - Page 11 SIZES: Light output： 11/14...
-
Page 12: Electrical Diagram
Electrical Diagram 12/14... -
Page 13: Component Order Codes
COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 230090003 SIGNAL CABLE 192010169 POWER SUPPLY 230060368 DRIVER BOARD 230060366 DIGITAL DISPLAY BOARD (PR3800T) 150020256 LED BOARD CT 3200K (PR3800D) 150020257 CT 5600K LED BOARD 13/14... - Page 14 PR LIGHTING LTD. PR New Hi-tech Science Park, 1582 Xingye Avenue Nancun Panyu, Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020119B Version：20141008 14/14...
