- Page 1 LED Studio 3201D LED Studio 3201T This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
-
Page 2: Table Of Contents
INDEX SAFE USAGE OF THE PROJECTOR……………………………………………………………………………… INSTALLING THE PROJECTOR…………………………………………………………………………………... CONTROL CONNECTION………………………………………………………………………………………… DMX TERMINATOR………………………………………………………………………………………………. SETUP OPTIONS-PROJECTOR CONFIGURATION……………………………………………………………… TO SET THE DMX START ADDRESS…………………………………………………………………………….. OPERATION MENU……………………………………………………………………………………………….. DMX PROTOCOL………………………………………………………………………………………………….. MAINTENANCE…………………………………………………………………………………………………… TROUBLESHOOTING……………………………………………………………………………………………… TECHNICAL DATA………………………………………………………………………………………………… ELECTRICAL DIAGRAM………………………………………………………………………………………….. COMPONENT ORDER CODES……………………………………………………………………………………. BACK COVER ……………………………………………………………………………… ………………..Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice. -
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton, check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector can be used indoors and outdoors, IP20. -
Page 4: Installing The Projector
INSTALL THE PROJECTOR The unit was designed to make installation easy: The fixture’s head can be rotated within 240°manually, before it rotates, two side retainers are loosened with care; after the head at a desired angle, tighten two side retainers.. Take 1 clamps and 1 safety cord out from the package and mount 1 clamps on the handle of fixture with 1 retainer attached to the clamp. -
Page 5: Control Connection
CONTROL CONNECTION Connection between the controller and a projector and between one projector and another must be made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Please use the projector’s cannon 5- pin signal input and output cables as connection. The 5-pin signal connections are connected as shown in the figure above. -
Page 6: Setup Options-Projector Configuration
SETUP OPTIONS-PROJECTOR CONFIGURATION To browse through or change a projector’s configuration, push ENTER for about 3seconds to unlock it, after which the DMX Address is shown meaning the menus have been entered into. TO set or browse through its functions, push the button of UP or DOWN. -
Page 7: Operation Menu
OPERATION MENU Level 1 menu Level 2 menu Level 3 menu Remarks DMX Address 001 - 512 DMX Address LED Dimmer 000 - 255 Value saved LED Lamp brightness Display Inversion Language Setup English Language Options Chinese Always on Config Setup Backlight off 1 minutes after neither button is 1 minutes pushed after the menus are exited... -
Page 8: Maintenance
MAINTENANCE To prolong the life of the projector, it is very important to do the maintenance work. I f the projector is idle for a long time, damp, smoke or particularly dirty surroundings can cause greater accumulation of dirt on its cover and housing. So it should be cleaned to maintain an optimum light output and at the same time to prevent it from corrupted by acid gas. -
Page 9: Technical Data
TECHNICAL DATA VOLTAGES: 100~240V AC, 50/60Hz POWER CONSUMPTION: 120W@220V LED: Power consumption 150W Quantity 1pcs Manufacturers Rated LED Life 50000 Hours COLOUR TEMPERATURE: PR-3201D 5600K PR-3201T 3200K Ra≥93 Luminous Flux: PR-3201D 22°：4500lm 85°：6800lm PR-3201T 22°：3600lm 85°：6100lm DIMMER: 0-100% linearly adjustable BEAM ANGLE: Spot Light Field angle(one-tenth-peak) θ：... - Page 10 WORK ENVIRONMENT TEMPERATURE: -20°C~40°C WEIGHT: SIZES: LIGHT OUTPUT: 10/14...
-
Page 11: Electrical Diagram
ELECTRICAL DIAGRAM 11/14... -
Page 12: Component Order Codes
COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK SIGNAL CABLE 230090003 120080070 1.5m POWER CORD POWER SUPPLY 192010190 200W 48V 230060367 DRIVER BOARD LCD DISPLAY 230060364 150020282 PR-3201T 3200K LED LAMP LED LAMP 150020283 PR-3201D 5600K 070050080 DIN15560 FRESNEL LENS 030060085 ￠135X25 12/14... - Page 13 13/14...
-
Page 14: Back Cover
PR LIGHTING LTD. PR New Hi-tech Science Park, 1582 Xingye Avenue Nancun Panyu, Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020292 Version: 20150508 14/14...
