- Page 1 LED Studio 3305D This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
-
Page 2: Table Of Contents
INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR CONTROL CONNECTION DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU DMX PROTOCOL INDICATION OF LED DIGITAL TUBE MAINTENANCE TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM COMPONENT ORDER CODES Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice. -
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton, check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector can be used indoors and outdoors, IP20. - Page 4 INSTALL THE PROJECTOR The unit hanging installation, not suitable for side hanging installation The unit was designed to make installation easy: it can be rotated within 90°manually; its two side panels can be rotated within 180°manually. Take 1 clamps and 1 safety cord out from the package and mount 1 clamp on the mounting ring of fixture with 1 retainer.
-
Page 5: Control Connection
CONTROL CONNECTION Connection between the controller and a projector and between one projector and another must be made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Please use the projector’s cannon 5- pin signal input and output cables as connection. -
Page 6: Setup Options-Projector Configuration
SETUP OPTIONS-PROJECTOR CONFIGURATION Projector configuration can be set conveniently via push-button switch and LED display. Launch the projector and press button FUNC for more than 3 seconds to unlock the panel, the LED will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function. For details, please see the “OPERATION MENU”... -
Page 7: Operation Menu
Operations Menu level menu level menu DMX Address （001~512） 000-255 Test Mode Address displayed after LED display locked Information Black LED display after it locked 7/16... -
Page 8: Dmx Protocol
DMX PROTOCOL CHANNEL FUNCTION DESCRIPTION Dimmer 000-255 Dimming from dark to light Manual Potentiometer Dimmer : Rotate the potentiometer from dark to bright(000~255) Manual Potentiometer Dimmer is prior to DMX Dimmer, Potentiometer @0 is the point to change between the two modes. Only Manual Potentiometer @0 can DMX Dimmer work, otherwise ,DMX Dimmer won’t work. -
Page 9: Indication Of Led Digital Tube
INDICATION OF LED DIGITAL TUBE DMX Address Address Indication Flash DMX Address changed Brightness Value Dimmer Indication Flash Brightness changed Setup status Display Indication Flash Setup changed DMX Signal OK，Receiving function OK DMX Indication DMX Signal BAD，Receiving function BAD MAINTENANCE To prolong the life of the projector, it is very important to do the maintenance work. -
Page 10: Technical Data
TECHNICAL DATA VOLTAGES: 100V-240VAC, 50/60Hz POWER CONSUMPTION: PR-3300T/ PR-3300D 80W@220V PR-3305T/ PR-3305D 140W@220V LED: Power consumption Quantity 5pcs PR-3300T/ PR-3300D 10pcs PR-3305T/ PR-3305D Manufacturers Rated LED Life More than 30000 Hours COLOUR TEMPERATURE: PR-3300T / PR-3305T 3200K PR-3300D / PR-3305D 5600K COLOUR RENDERING INDEX: Ra=93... - Page 11 SIZES: 11/16...
-
Page 12: Electrical Diagram
ELECTRICAL DIAGRAM 12/16... - Page 13 13/16...
-
Page 14: Component Order Codes
COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 212020014 SIGNAL MALE 212020015 SIGNAL FENALE 120080070 1.5m POWER CORD 190010121 100-240V POWER SUPPLY 230020484 PR-3300T/PR-3300D LED CONTROL BOARD LED CONTROL BOARD 230020482 PR-3305T/PR-3305D 150020232 PR-3300T LED BOARD 150020233 PR-3300D LED BOARD 150020234 PR-3305T LED BOARD... - Page 15 15/16...
- Page 16 PR LIGHTING LTD. PR New Hi-tech Science Park, 1582 Xingye Avenue Nancun Panyu, Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 321030063A Version: 20131022 16/16...
