Check Of Settings - Danfoss AK-CC 750 series Manual

Check of settings

1. Go to the overview
2. Select evaporator A
3. Settings for thermostat
4. Move on with the next display for the section. Here
the alarm thermostat
Press the blue overview button at the bottom left of the
display.
5. Settings for alarm thermostat
60 RS8GM222 © Danfoss 10-2014
Before the control starts, we check that all the settings are as they should
be.
The overview display will now show one line for each of the general
functions. Behind each icon there is a number of displays with the
different settings. It is all these settings that have to be checked.
Remember the settings at the bottom of the pages – the ones that can
only be seen via the "Scroll bar".
Page 2 shows a sum-
mary of the temperature
sequence over the past 24
hours.
Remember the settings at the bottom of the pages – the ones that can
only be seen via the "Scroll bar". "
AK-CC 750 - 080Z0130 & 080Z0139
