Danfoss AK-CC 750 series Manual page 15

Point
At the top the
signal input is
the left of the
two terminals.
At the bottom
the signal input
is the right of the
two terminals.
S
Pt 1000 ohm/0°C
P
AKS 32R
3: Brown
AKS 2050
2: Blue
1: Black
AKS 32
3: Brown
2: Black
1: Red
U
On/Off
AK-CC 750 - 080Z0130 & 080Z0139
Signal Signal
type
S2
S3
Pt 1000
S4
S5
Saux
AKS 32R
AKS 2050
P0
-1 - xx bar
Pc
Paux
AKS 32
-1 - zz bar
0 - 5 V
...
0 - 10 V
Active at:
Ext.
Main
Closed
switch
/
Day/
Open
Night
Door
Defrost
RS8GM222 © Danfoss 10-2014
Point 1 2 3 4
Type AI1 AI2 AI3 AI4
Point 5 6 7
Type AI5 AI6 AI7
Signal Module
9:
Terminal
10:
Terminal
15:
Terminal
16:
Terminal
Terminal
11, 12, 13, 14:
(Cable screen)
8
AI8
Point
Terminal
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5 (AI 5) 17 - 18
6 (AI 6) 19 - 20
7 (AI 7) 21 - 22
8 (AI 8) 23 - 24
12 V
5 V
5 V
12 V
Signal type /
Active at
15
