Determine the connection points

All connections must be programmed with module and point, so
in principle it does not matter where the connections are made, as
long as it takes place on a correct type of input or output.
• The controller is the first module, the next one is 2, etc.
• A point is the two or three terminals belonging to an input or
output (e.g. two terminals for a sensor and three terminals for a
relay).
The preparation of the connection diagram and the subsequent
programming (configuration) should take place at the present
time. It is most easily accomplished by filling in the connection
survey for the relevant modules.
Principle:
Name On module
fx Compressor 1
fx Compressor 2
fx Alarm relay
fx Main switch
fx P0
The connection survey from the controller and any extension
modules are uploaded from the paragraph "Module survey. E.g.
controller module:
Signal Module
- Columns 1, 2, 3 and 5 are used for the programming.
- Columns 2 and 4 are used for the connection diagram.
Example continued:
Signal
Air temperature - S3A
Air temperature- S3B
Air temperature- S3C
Air temperature - S4A
Air temperature - S4B
Air temperature - S4C
Defrost sensor - S5A
Defrost sensor - S5B
Defrost sensor - S5C
Gas temperature - S2A
Evaporator pressure - P0
AKV A
AKV B
AKV C
Fans
Defrost A
Defrost B
Defrost C
Rail heat
AK-CC 750 - 080Z0130 & 080Z0139
On Point Function
x x ON
x x ON
x x OFF
x x Close
x x AKS 32R 1-6 bar
Signal type /
Point Terminal
Active at
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
Module Point Terminal
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5 (AI 5) 9 - 10
6 (AI 6) 11 - 12
7 (AI 7) 13 - 14
8 (AI 8) 19 - 20
9 (AI 9) 21 - 22
10 (AI 10) 23 - 24
1
11 (AI 11) 25 - 26
12 (DO 1) 31 - 32
13 (DO 2) 33 - 34
14 (DO 3) 35 - 36
15 (DO 4) 37 - 38
16 (DO 5) 39-40-41
17 (DO6) 42-43-44
18 (DO7) 45-46-47
19 (DO8) 48-49-50
24 -
25 -
RS8GM222 © Danfoss 10-2014
Tip
The Appendix shows 80 general installation types.
If your plant closely resembles one of those shown, you
can use the connection points indicated for it.
Signal type /
Signal
Active at
Pt 1000
Gas temperature - S2B
Pt 1000
Gas temperature - S2C
Pt 1000
External Start/stop
Pt 1000 Case cleaning (pulse pressure)
Pt 1000
Pt 1000
Pt 1000
Pt 1000
Pt 1000
Pt 1000
AKS32R-12
-
-
-
ON
ON
ON
ON
ON
Module Point
Mind the numbering.
The right-hand part of the
controller module may look like
a separate module. But it isn't.
Module Point Terminal
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
2
5 (AI 5) 17 - 18
6 (AI 6) 19 - 20
7 (AI 7) 21 - 22
8 (AI 8) 23 - 24
Signal type /
Active at
Pt 1000
Pt 1000
Closed
Closed
