AK-CC 750 - 080Z0130 & 080Z0139
Point
1
Type
DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8
Signal
Active at
Fan
Alarm
On
Light
/
Railheat
Off
Defrost
Night
blind
Valve
Compres-
sor
RS8GM222 © Danfoss 10-2014
2
3
4
5
6
7
8
Signal
Module
Point
Terminal
1 (DO 1)
25 - 27
2 (DO 2)
28 - 30
3 (DO 3)
31 - 33
4 (DO 4)
34 -36
5 (DO 5)
37 - 39
6 (DO 6)
40 - 41 - 42
7 (DO 7)
43 - 44 - 45
8 (DO 8)
46 - 47 - 48
Active at
19
