Cable connections

This chapter includes the following topics:

About the cables

The NetBackup appliances and storage devices use the following cables.
Cables shipped with the product:
Cables which the customer must provide:
About the cables
Connecting the VGA cable
Connecting the network cables
Connecting the appliance to one or more storage shelves
Connecting the small form-factor pluggable (SFP+) transceivers
Connecting the power cables
Power Distribution Unit (PDU) cords for connecting the devices to main AC
power source
Most NetBackup appliances and storage shelves ship with two PDU compatible
cords (C13-C14). AC power cables ship to limited, specified, countries.
SAS cables to connect the appliance to a storage device and to connect storage
devices to each other.
1 Gb/s network cables
10 Gb/s network cables
Fibre Channel cables for client and device connections
KVM cable
