ABBREVIATIONS AND SYMBOLS USED IN THIS MANUAL
FE = Functional earth (earth connection)
M/S = Master/Slave System
OSSD = Output Signal Switching Device (Light curtain's solid state safety outputs)
TX = Safety light curtain emitter.
RX = Safety light curtain receiver.
Hand protection light curtains
Arm and leg protection light curtains.
Full body protection light grids.
This symbol indicates an important warning for personal safety. Failure to comply
with this warning may result in high level risk for exposed personnel.
This symbol indicates an important warning.
2
EOS2 SAFETY LIGHT CURTAIN
8540738 • 2nd December 2009 • Rev.2
