Emitter connections

STANDARD - WITH INTEGRATED CONTROL FUNCTIONS - MASTER MODELS
M12 5-pin primary connectors.
RANGE AND TEST SELECTION - (PRIMARY CONNECTOR M12, 5 PIN)
PIN 4
24V
0V
0V
24V
For correct operation of the light curtain, pins 2 and 4 of the Emitter must be
connected as indicated in
SLAVE/SLAVE2 MODELS - M12, 5-pin primary connector.
MASTER MODELS – M12, 5-pin secondary connector.
SLAVE2 MODELS – M12, 5-pin secondary connector.
16
PIN COLOUR NAME
1 Brown 24VDC
2 White RANGE0
3 Blue 0VDC
4 Black RANGE1
5 Grey FE
Master/Standard/with integrated control functions TX
PIN 2
0V
24V
0V
24V
Table 5 – Range and TEST selection
Table 5 .
PIN COLOUR
1 Brown
2 White
3 Blue
4 Black
5 Grey
Table 6 - M12, 5-pin Primary Slave TX
PIN COLOUR
1 Brown
2 White
3 Blue
4 Black
5 Grey
Table 7 - M12, 5-pin Secondary TX
TYPE
24VDC power supply
Light curtain configuration
complying with the EN61131-2 standard
INPUT
0VDC power supply
Light curtain configuration
complying with the EN61131-2 standard
Ground connection
Table 4 - M12, 5 pin
MEANING
Selection HIGH Range
Selection LOW Range
Emitter in TEST
Selection error
NAME
24VDC
LINE_A
0VDC
LINE_B
FE
NAME
24VDC
LINE_A
0VDC
LINE_B
FE
8540738 • 2nd December 2009 • Rev.2
EOS2 SAFETY LIGHT CURTAIN
DESCRIPTION
(ref. Table 5)
(ref. Table 5)
DESCRIPTION
24VDC power supply
Communication
MASTER-SLAVE
0VDC power supply
Communication
MASTER-SLAVE
Ground connection
DESCRIPTION
24VDC power supply
Communication
MASTER-SLAVE
0VDC power supply
Communication
MASTER-SLAVE
Ground connection
