  • Page 1 PHOTOELECTRIC SAFETY BARRIER JANUS TRX Ó Ó www.reer.it...

  • Page 2: Table Of Contents

    PHOTOELECTRIC SAFETY BARRIER JANUS TRX INSTALLATION USE AND MAINTENANCE INDICE INTRODUCTION ........................2 PRINCIPLE OF OPERATION ....................3 INSTALLATION ........................5 POSITION ............................6 MULTIPLE SYSTEMS ........................6 SAFETY DISTANCE CALCULATION ....................7 VERTICAL POSITION OF THE BARRIER ..................8 ELECTRICAL CONNECTIONS .....................8 EXTERNAL CONNECTION ......................9 DISTANCE BETWEEN REFLECTING SURFACES ..............

  • Page 3: Introduction

     This symbol stands by a very important warning concerning the safety of persons. Its non-observance can cause a very serious risk for the exposed personnel. INTRODUCTION The J TRX safety light curtain is a multi-beam opto-electronic safety system of the Type 4 category of electro-sensitive devices in accordance with IEC61496-1,2 EN61496-1, for the protection of persons exposed to dangerous machines or plants.

  • Page 4: Principle Of Operation

    PRINCIPLE OF OPERATION Figure 1 shows the MI/ML/MT TRX way of operation : The active element M TRX E/R contains the emitter and the receiver units; the emitted infrared beam, correctly reflected by the pre-aligned deflection mirrors of the passive element TRX RR, is received by the receiver of the M TRX E/R.
  • Page 5 ACTIVE ELEMENT PASSIVE ELEMENT MIRROR1 RECEIVER1 MIRROR2 EMITTER1 MIRROR3 EMITTER2 MIRROR4 RECEIVER2 Figure 3 - J TRX con 4 raggi 8540568 - 12/09/2022 - Rev.6...

  • Page 6: Installation

    INSTALLATION Before installing the JANUS TRX safety system, make sure that:  The safety system is only used as a stopping device and not as a machine control device.  The machine control can be actuated electrically.  All dangerous machine movements can be interrupted immediately. In particular, the machine stopping times must be known and, if necessary, measured.

  • Page 7: Position

    To reach the perfect JANUS TRX installation, position both the units as showed in Figure 4 (REER labels in the same side) Figure 4 MULTIPLE SYSTEMS JANUS TRX is composed of one active and one reflecting element; when more than one JANUS TRX system is used, precaution must be taken to avoid optical interference between them.

  • Page 8: Safety Distance Calculation

    SAFETY DISTANCE CALCULATION The barrier must be installed at a distance that is greater than or equal to the minimum safety distance S, so that a dangerous point can only be reached after all hazardous machine movements have stopped (Figure 3). According to European standard EN999, the minimum safety distance S must be calculated using the following formula: S = K (t...

  • Page 9: Vertical Position Of The Barrier

    VERTICAL POSITION OF THE BARRIER point of danger  These models are suitable for the protection of the entire body and must not be used to protect safety arms or legs. barrier The minimum safety distance S is calculated according to the following formula: S = 1600 (t ) + 850 ➔...

  • Page 10: External Connection

    Connector pins. Figure 7 EXTERNAL CONNECTION COLOR NAME TYPE DESCRIPTION OPERATION 24VDC 24VDC power supply Brown 0VDC 0VDC Blue Ground connection OSSD1 OUTPUT White Safety static outputs PNP active high OSSD2 OUTPUT Green EXT_SEL_A INPUT Barrier Grey According the normative configuration EXT_SEL_B INPUT...

  • Page 11: Distance Between Reflecting Surfaces

    DISTANCE BETWEEN REFLECTING SURFACES The presence of reflecting surfaces in proximity of the photoelectric barrier may generate spurious reflections that prevent monitoring. With reference to Figure 8, object A is not detected because surface S reflects the beam and closes the optical path between the active and passive elements.
  • Page 12 Figure 9 After installing the system, check whether any reflecting surfaces intercept the beams, first in the centre and then in the vicinity of the active unit. During these operations, the red LED on the active elements should never, for any reason, switch off.

  • Page 13: Mounting And Optical Alignment

    MOUNTING AND OPTICAL ALIGNMENT The active element J TRX E/R and the the passive element J TRX RR must be mounted the first in front of the other with the same (or less) distance showed in the technical data. Using the fastening brackets and inserts (available on request) fix the active element J TRX E/R and the passive element J TRX RR aligned and parallel.

  • Page 14: Operation And Technical Data

    OPERATION AND TECHNICAL DATA LIGHT SIGNALS ACTIVE ELEMENT SIGNALS At power-on, for a period of 5 seconds, the display will show the number "8" and all the leds will be ON. In the next 10 seconds, the display and the leds will show the configuration selected.
  • Page 15 Normal display NORMAL OPERATION COLOR (LED ON) (LED OFF) Weak signal received Signal received OK ORANGE Weak (1) Light curtain occupied, OSSD outputs set OFF Break (2) Light curtain clear, GREEN OSSD outputs set ON Guard (3) Light curtain clear, OSSD outputs set OFF (the receiver is waiting for a Clear (4) CLEAR...

  • Page 16: Configuration And Operation Modes

    CONFIGURATION AND OPERATION MODES The JANUS TRX operation mode is selected realizing appropriate connections on the M12 8 poles of the active element (Table 1 and Table 2). AUTOMATICO MODE In this operation mode the OSSD1 and OSSD2 safety outputs follow the barrier status : with proteceted area clear, the safety outputs are active.
  • Page 17 Figure 13 Example of connection of TRX barrier in AUTOMATIC mode without feedback K1K2 MANUAL MODE In this operating mode the safety outputs OSSD1 and OSSD2 are activated (+24VDC) only if the protected area is free and after the reception of the RESTART signal, using a push button or thank to an appropriate control on the SEL_A or SEL_B input (ref.Table 3).
  • Page 18 Figure 14 Example of connection of TRX barrier in MANUAL mode with feedback K1K2 Figure 15 Example of connection of TRX barrier in MANUAL mode without feedback K1K2 8540568 - 12/09/2022 - Rev.6...

  • Page 19: K1/K2 External Contactors Connection

    K1/K2 EXTERNAL CONTACTORS CONNECTION In every operating mode is activable the K1/K2 external contactors feedback. If you want to use this check, connect the pin 4 of 8 poles M12 connector with the power supply (+24VDC) through the series of N.C. contacts (feedback) of external contactors. OUTPUT STATUS Janus TRX features two static PNP outputs on the active element, the status of which depends on the condition of the protected area.

  • Page 20: Technical Specifications

    TECHNICAL SPECIFICATIONS GENERAL DATA Safety category Reset automatic or manual selectable Power supply 24  20% Connections M12 – 8 poles (male) Protection rating IP 65 Max. length of electrical connections Dimensions light 50 x 60 curtain section 0...55 Operating temperature °C Storage temperature °C...

  • Page 21: Dimensions

    DIMENSIONS ACTIVE PASSIVE ELEMENT ELEMENT ACTIVE PASSIVE ELEMENT ELEMENT ACTIVE PASSIVE ELEMENT ELEMENT J 2B TRX J 3B TRX Figure 17 Figure 18 Figure 19 8540568 - 12/09/2022 - Rev.6...

  • Page 22: Checkouts And Maintenance

    If the orange weak signal LED on the active uniit switches on (LED 1 in Figure 11), check that: – the front surfaces are clean; – the active and passive elements are aligned correctly. If the LED stays on, contact the REER service department. 8540568 - 12/09/2022 - Rev.6...

  • Page 23: Troubleshooting

    If necessary re-dimension the load by reducing the request to a max. of 500 mA (2.2 F) Internal error Send the equipment for repairs to an REER laboratory. Internal error Send the equipment for repairs to an REER laboratory.
  • Page 24 In any case, when faced with a system stoppage, switch the system off and then on again, to exclude any occasional electromagnetic disturbances. Should the problem persist, contact REER’s service department. In case of continued malfunctioning: verify the integrity of electrical connections and check that these have been •...

  • Page 25: Spare Parts

    SPARE PARTS CONNECTORS Straight 8-pin M12 female connector, 5 m cable 1330980 C8D5 Straight 8-pin M12 female connector, 10 m cable 1330981 C8D10 Straight 8-pin M12 female connector, 15 m cable 1330982 C8D15 90° 8-pin M12 female connector, 5 m cable 1330983 C8D95 90°...

  • Page 26: Ce Declaration Of Conformity

    CE DECLARATION OF CONFORMITY 8540568 - 12/09/2022 - Rev.6...

  • Page 27: Ukca Declaration Of Conformity

    UKCA DECLARATION OF CONFORMITY ReeR declares that JANUS photoelectric safety barriers complies with following UK legislation: • S.I. 2008 No. 1597 - The Supply of Machinery (Safety) Regulations S.I. 2016 No. 1101 - Electrical Equipment (Safety) Regulations • S.I. 2016 No. 1091 - Electromagnetic Compatibility Regulations •...

  • Page 28: Guarantee

    GUARANTEE All new JANUS TRX systems are guaranteed by REER for a period of 12 (twelve) months under normal working conditions, against defects due to faulty materials and workmanship. During the aforesaid period, REER promises to replace faulty parts free of charge. This guarantee covers both material and labour.
  • Page 29 REER S.p.A. via Carcano 32 10153 Torino Italia Tel. +39/0112482215 r.a. Fax +39/011859867 Internet: www.reersafety.com e-mail: info@reer.it...
