Installing a CompactFlash card
Before installing or removing a CompactFlash card, make sure
the system is powered off and the power supply is discon-
nected.
To prevent damage to the ReadyBoard or the CompactFlash
card, make sure the system is powered off and the power sup-
ply is disconnected before installing or removing a Compact-
CAUTION:
Flash card.
Use a phillips screwdriver to remove the two screws securing
the CompactFlash socket cover as shown below.
M3x0.5 Screws (2)
(Flat Head, 3mm)
CompactFlash
Protective Cover

Figure 2-2: Removing the CF socket cover
