9. Adjust the camera's angle, focus and zoom of the camera.
Pan Adjustment
Rotation al Adjustmen
10. Replace the silica gel bag, press all the wires and cables into the
notch and secure the camera cover with the torx wrench.
Figure 4-21
78
Vandal Proof IP Dome (Part IV)
4
t
Figure 4-20
Tilt Adjustment
