GV-VD120D /121D / 122D / 123D
Models
Model
GV‐VD120D
GV‐VD121D
GV‐VD122D
GV‐VD123D
Active Tampering Alarm
Tampered
GV-VD120D/121D/122D/123D
1.3MP H.264 Low Lux IR Vandal Proof IP Dome
*No Memory card slot & local storage function for Argentina.
Housing Cover
Cover Color
Transparent cover
Smoked cover
Transparent cover
Smoked cover
Focus Change
- 1 -
•
1/3" progressive scan Low Lux CMOS
•
Dual streams from H.264 and MJPEG
•
Up to 30 fps at 1280 x 1024
•
Vandal resistance IK10+
(for GV‐VD120D and GV‐VD121D only)
•
Vandal resistance IK7
(for GV‐VD122D and GV‐VD123D only)
•
Ingress protection (IP66)
•
Varifocal megapixel lens
•
3‐axis mechanism (pan / tilt / roll)
•
Removable IR‐cut filter for Day/Night
function
•
External microphone
•
Intelligent IR
•
2‐way audio
•
One sensor input and alarm output
•
TV‐out support
•
Memory card slot
•
DC12V / AC24V / PoE
•
Wide Dynamic Range (WDR)
•
Defog
•
Motion detection
•
Tampering alarm
•
Privacy mask
•
IP address filtering
•
Supports iPhone, iPad, Android &
3GPP
•
31 languages on Web interface
•
ONVIF conformant
Vandal Resistance
IK10+
IK10+
IK7
IK7
Camera Shift
December 24, 2012
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GeoVision GV-VD120D
Summary of Contents for GeoVision GV-VD120D
- Page 1 GV-VD120D /121D / 122D / 123D 1.3MP H.264 Low Lux IR Vandal Proof IP Dome • 1/3" progressive scan Low Lux CMOS • Dual streams from H.264 and MJPEG • Up to 30 fps at 1280 x 1024 • Vandal resistance IK10+ (for GV‐VD120D and GV‐VD121D only) • Vandal resistance IK7 (for GV‐VD122D and GV‐VD123D only) • Ingress protection (IP66) • Varifocal megapixel lens • 3‐axis mechanism (pan / tilt / roll) ...
- Page 2 G.711, AAC (16 kHz / 16 bit) Audio Compression * AAC is only supported by GV‐System V8.5 or later Two‐way Audio Yes Sensor Input 1 Input (Dry Contact) Alarm Output 1 Digital Output (200mA 5V DC) Video Resolution 4:3 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 5:4 1280 x 1024, 640 x 512, 320 x 256 4:3 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252 5:4 640 x 512, 320 x 256 Network Interface 10/100 Ethernet - 2 - GV-VD120D/121D/122D/123D December 24, 2012...
- Page 3 Web Interface Installation Management Web‐based configuration Maintenance Firmware upgrade through Web Browser or Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, Access from Web Browser digital I/O control, audio, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Persian / Language Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish Applications Network Storage GV‐NVR, GV‐System, GV‐Backup Center, GV‐Recording Server GV‐Eye for Android smartphone, tablet, iPhone, and iPod Touch Smart Device Access GV‐Eye HD for iPad Live Viewing IE, GV‐MultiView CMS Server support GV‐Control Center, GV‐Center V2, GV‐VSM Note: 1. Do not use clothes or any ordinary material to clean the camera cover since they may result in scratches. 2. Specifications are subject to change without notice. - 3 - GV-VD120D/121D/122D/123D December 24, 2012...
