View Input Weighting and Gear

1. In the main menu, click
Performance Statistics.
2. Click System Loop Statistics.
3. View the weight given to each
input for BesTime ensembling
computation.
4. View the stage (gear) in the
time calculation process.
Gears 1, 2, and 3 are warm-up
processes after power-up. Gears 4,
5, and 6 indicate a settling period
when the TimeSource 2700
outputs Stratum 1 signals. Gear 7
indicates steady-state operation.
S S S S S S S S S S S S S S S S
1
2
S S S S S S S S
3 4
83
Operation
