View Daily Holdover Information (cont'd)
8. Click to start or stop the log file
for this screen.
Data from the screen is written to
the file at every screen update while
the box is checked. The log file may
be opened and read during the
logging process; however, the log file
is read-only during the logging
process. The log file is written in a
comma-delimited (.csv) data
format.
9. Click the pull-down arrow to
select the number of minutes
between screen updates.
10. View which input is being
measured.
11. View the drift, in parts per
billion per day, predicted for this
input during the current 24 hour
period.
12. View the predicted error in ns.
This error can be held for up to
24 hours if the TimeSource 2700
goes into holdover.
